Specifications
| Model Name | RS495LHW01D01 |
| Screen Size | 49.5 inch |
| Display Area (mm) | 1209.6(W)×340.2(H) mm |
| Brightness | 500~5000NITS |
| Resolution | 1920(RGB)×540, 40PPI |
| Aspect Ratio | above 3:1 |
| Contrast Ratio | 4000:1 |
| Pixel Pitch (mm) | 0.630×0.630 mm (H×V) [40PPI] |
| Viewing Angle | 178°(H),178°(V) |
| Color Saturation | 16.7M 50% NTSC |
| Display Colors | 16.7M |
| Response Time (Typical) | 8 (Typ.)(G to G) |
| Input Interface | HDMI*1 VGA*1 AUDIO IN*1 HDMI*1DVI*1( USB*1 BNC*1 AV*1 options) OSD Key 6 Keys |
| Input Power | AC100~240V |
| Dimensions (mm) | 1230(L)*370.2(H)*48.00(W) |
| Mounting | 300x400mm |
| Weight (Net) | 12.1KG |
| Operating Temperature | -20~70 °C |
| Storage Temperature | -30~80 °C |
RS495LHW01D01 is a 49.5-inch LCD display with 500 nits brightness, 1920×540 resolution and 4000:1 contrast ratio. Its operating temperature range is -20 °C to 70 °C.

RS495LHW01D01 – Specification Table
| Item | Specification |
|---|---|
| Model Name | RS495LHW01D01 |
| Screen Size | 49.5 inch |
| Display Area (mm) | 1209.6(W) × 340.2(H) |
| Brightness | 500–5000 nits |
| Resolution | 1920(RGB) × 540, 40 PPI |
| Aspect Ratio | Above 3:1 |
| Contrast Ratio | 4000:1 |
| Pixel Pitch (mm) | 0.630 × 0.630 mm (H×V), 40 PPI |
| Viewing Angle | 178° (H) / 178° (V) |
| Color Saturation | 16.7M, 50% NTSC |
| Display Colors | 16.7M |
| Response Time | 8 ms (G to G) |
| Input Interface | HDMI1, VGA1, Audio In1, DVI1, USB1, BNC1, AV*1 (options), OSD Keys: 6 |
| Input Power | AC 100–240V |
| Dimensions (mm) | 1230(L) × 370.2(H) × 48.0(W) |
| Mounting | 300 × 400 mm |
| Weight (Net) | 12.1 kg |
| Operating Temperature | -20 ~ 70 °C |
| Storage Temperature | -30 ~ 80 °C |
Product Description
The RisingStar RS495LHW01D01 is a 49.5-inch ultra-wide high brightness LCD display designed for industrial and outdoor digital signage applications. With brightness levels ranging from 500 to 5000 nits, it delivers clear, sunlight-readable visibility even in harsh outdoor environments. Its 3:1 aspect ratio, 4000:1 contrast, and wide viewing angles ensure excellent image clarity for long-distance and multi-angle viewing.
Equipped with versatile interfaces including HDMI, VGA, DVI, USB, BNC, and AV, the display supports flexible system integration in transportation, retail, EV charging stations, kiosks, and passenger information systems. The robust design includes -20 ~ 70 °C operating temperature, making it suitable for extreme weather conditions. Its lightweight structure and 300×400 mm VESA mounting allow easy installation in narrow or elongated spaces.
Typical Applications
Outdoor digital signage displays
Transportation passenger information systems (railway, metro, bus)
EV charging station screens
Retail store window-facing displays
Industrial control and monitoring terminals
Wayfinding and public information kiosks
Petrol station digital price boards & media displays
Product FAQs
-
It is rated at 500 nits (cd/m²) brightness.
-
It uses a 49.5-inch panel, 1920×540 resolution, 4000:1 contrast ratio.
-
The operating temperature range is -20 °C to 70 °C.
-
Yes. RisingStar is an OEM/ODM manufacturer and accepts customization requirements for volume orders; contact the sales team with your target specification.
-
It adopts HDMI*1 VGA*1 AUDIO IN*1 HDMI*1DVI*1( USB*1 BNC*1 AV*1 options) OSD Key 6 Keys interface.
-
The power input requirement is AC100~240V.
-
The pixel pitch is 0.630×0.630 mm (H×V) [40PPI].
-
The viewing angle is 178°(H),178°(V).
