Specifications
| Item No | RS2150ENT-N10T Touched |
| Panel Brand | AUO display |
| Panel No | G215HVN01.3 |
| Size | 21.5 inch |
| Panel Type | a-Si TFT-LCD, LCM |
| Resolution | 1920(RGB)×1080 [FHD] 102PPI |
| Pixel Format | RGB Horizontal Stripe |
| Display Area | 476.64 × 268.11 mm (H×V) |
| Outline Size | 479.84 × 271.31 mm (H×V) |
| Surface Treatment | Antiglare, hard coating (3H) |
| Brightness | 1000cd/m² |
| Constrast Ratio. | 5000:1 |
| Aspect Ratio: | 16:9 |
| Viewing Angle | 89/89/89/89 (Typ.)(CR≥10) |
| Display Model | VA, Normally Black, Transmissive |
| Response Time | 20/5 (Typ.)(Tr/Td) ms |
| Display Color | 16.7B 72% NTSC |
| Backlight | WLED, 50K hours, W/ LED Driver |
| Touch type | resistive/capacitive/mouse control |
| Frame Rate | 60Hz |
| Operation system: | Android 5.1 |
| Memory adn storage: | 2GB+8G |
| Power performance | 100-240v |
| Power | 33W |
| Network ports | LAN*1, WIFI *1 |
| Storage extension: | Micro SD card |
| other ports | USB2.0*2, SIM Card*1, AC switch, DVI, VGA, HDMI |
| Operating Temperature | -20~70 °C |
| Storage Temperature | -30~80 °C |
RS2150ENT-N10T is a 21.5-inch LCD display with 1,000 nits brightness, 1920×1080 resolution and 5000:1 contrast ratio. Its operating temperature range is -20 °C to 70 °C.
RS2150ENT-N10T is a industrial touch LCD monitor, this provide high brightness and sunlight readability, powerful, compact, rugged and energy saving.
This industrial touch LCD monitor is completely and easily configurable, boast advanced thermal management and with an all aluminum frame, and are combat-proven and field tested to withstand shock and vibration, extended temperature range and extreme environments.
It is ideal for digital factory, transport, marine, retail and medical device.
RS2150ENT-N10T industrial touch LCD monitor Main features
• 1920x1080 high resolution, 16 : 9 aspect ratio
• Projective capacitive multi-touch or single-point resistive touch
• High brightness 1000cd/m2 with long-life LED backlight
• Front IP65 compliant flat panel monitor
• Automatic backlight adjustment through a built-in ambient light sensor
• VGA, HDMI, and DVI with multi-signal inputs
•Excellent price-performance ratio
•100% tested and high quality
• Easy to maintain
• Fast shipment
Panel Mount Monitor, Embedded Mount Monitor
The most polular installation ways for most application is mounted montors, embedded monitor, our RS2150ENT-N10T industrial touched LCD monitors with ultra-thin front bezels, suitable for embedding into other equipment surface, such as electronical panels, dashboards, doors,machine, etc. Realizing a true-flat seamless design style.
The RS2150ENT-N10T industrial touch LCD monitor supports multiple software
This industiral monitor offers a true multi touch capabilities – up to 20 simultaneous point of touch, touch gesture recognition – write with the pen and erase with your palm, fast touch response time, as well as easy to use and intuitive Android-based built-in software.
Product FAQs
How bright is the RS2150ENT-N10T?
It is rated at 1,000 nits (cd/m²) brightness.
What are the main display specifications?
It uses a 21.5-inch panel, 1920×1080 resolution, 5000:1 contrast ratio.
What is the operating temperature range?
The operating temperature range is -20 °C to 70 °C.
Is this product available for OEM or ODM customization?
Yes. RisingStar is an OEM/ODM manufacturer and accepts customization requirements for volume orders; contact the sales team with your target specification.
What is the viewing angle?
The viewing angle is 89/89/89/89 (Typ.)(CR≥10).
Is the RS2150ENT-N10T suitable for outdoor or high-ambient-light use?
Yes. Rated at 1,000 nits, it is a high-brightness panel built for sunlight-readable and outdoor applications.
How is the screen surface treated?
The panel surface treatment is Antiglare, hard coating (3H).
What panel technology does the RS2150ENT-N10T use?
It uses a-Si TFT-LCD, LCM.
