Specifications
| Panel | |
| display screen | LCD module |
| display size | 23.6 inches |
| display area | 521.5(W)×293.2(H) mm |
| display resolution | 1366*768 |
| Zoom | 1 6:9 |
| brightness, | 2000 cd/m2 (center point, t yp ), sunlight readable |
| Contrast | 5000:1 |
| viewing angle | 89/89/89/89(Min.)(CR≥10) |
| Response time | 8ms ( Gray To Gray ) |
| Uniformity of brightness | ≧ 75% |
| color depth | 16.7M |
| Operating Temperature | -20~70 °C |
| system configuration | |
| main chip | 68676 |
| multimedia | H265/H264 video decoding |
| system version | OSD |
| Interface | |
| input interface | USB * 1 DC*1 hdmi*1 VGA*1 |
| power input | AC 110-220V~50/60Hz |
RS236-OEM is a 23.6-inch LCD display with 2,000 nits brightness, 1366×768 resolution and 5000:1 contrast ratio. Its operating temperature range is -20 °C to 70 °C.
RisingStar 23.6 inch open frame sunlight readable tft LCD is with thin body design, high resolution, fast response and vivid color, the display is a light-weight, bright display designed for outdoor device,
Sunlight readable brightness 2000 nits
2000 nits, high brightness ensures that the screen remains visible even in direct sunlight, making it easy for people to read important information and messages.
Open frame
1. Thin profile: The open-frame design allows the display to have a thin profile, which makes it suitable for applications where space is limited.
2. Easy integration: The open-frame design makes it easy to integrate the display into different types of products.
3. Cost-effective: Open-frame displays are often more cost-effective than other types of displays because they do not have an additional enclosure.
4. Customizable: Open-frame displays can be customized to meet specific application requirements, such as size, resolution, and brightness.
5. Versatile: They are suitable for a wide range of applications, including gaming machines, industrial equipment, medical devices, and transportation systems.
Product FAQs
How bright is the RS236-OEM?
It is rated at 2,000 nits (cd/m²) brightness.
What are the main display specifications?
It uses a 23.6-inch panel, 1366×768 resolution, 5000:1 contrast ratio.
What is the operating temperature range?
The operating temperature range is -20 °C to 70 °C.
Is this product available for OEM or ODM customization?
Yes. RisingStar is an OEM/ODM manufacturer and accepts customization requirements for volume orders; contact the sales team with your target specification.
What interface does the RS236-OEM use?
It adopts USB * 1 DC*1 hdmi*1 VGA*1 interface.
What is the power input requirement for the RS236-OEM?
The power input requirement is AC 110-220V~50/60Hz.
What is the viewing angle?
The viewing angle is 89/89/89/89(Min.)(CR≥10).
Is the RS236-OEM suitable for outdoor or high-ambient-light use?
Yes. Rated at 2,000 nits, it is a high-brightness panel built for sunlight-readable and outdoor applications.
