    55 "outdoor LCD module

    2021-11-15 10:43:53  News

    As a cutting-edge product in the display industry, LCD technology is also developing and innovating, and the LCD screen is in short supply.  For outdoor display requirements are also gradually strict, due to the wide use of LCD module high temperature resistance and visibility requirements are becoming higher and higher, ordinary brightness LCD screen can not meet the requirements of color and picture saturation, the emergence of the highlight display can just solve this problem.

    The highlight display adopts side-in backlight mode to reduce the problem of high power consumption of the screen itself. The aluminum alloy shell greatly increases the heat dissipation function, realizing low power consumption and low heat, thus increasing the service life of the LCD panel.

    Risingstar 55 "outdoor high brightness LCD screen has the advantages of low power consumption, good heat dissipation performance and long service life.  Aluminum alloy shell, side into the backlight, brightness can achieve 1000-5000 nits, LG panel, good stability, clear picture, is the first choice for outdoor display.  55 inch LCD panel can be used for outdoor billboards, bus stops, gas stations, hotels, window display, outdoor and semi-outdoor advertising display.

           应用3

    Size

     55 inch

    Panel item

    RS550ENT-N05

    Panel type

    a-Si TFT-LCD

    Display mode

     IPS,Normally black.Transmissive

    Pixels

    1920*1080, FHD

    brightness

    500-5000cd/m2

    Constrast Ratio

    1200:1

    View angle

    89/89/89/89 (Min)

    View area

    1209.8*680.6mm(H*V)

    Dispaly area

    1209.6*680.4mm(H*V)

    Outline Size

    1242.1*718*40mm(H*V*D)

    Working freqyency

    60Hz

    Respone Time

    6ms

    Working temperature

    0- 50゚C

    Storage Temperature

    -20 - +60゚C

    Display ratio

    16:9

    Display color

    16.7m/1.7B

    Surface Treatment

    Haze 3%,hard coating 2H

    Weight

    17.7kgs
