Specifications

Screen Diagonal15  inch
Brand RisingStar
Model NoRS150X0M-GE10
Active Area304.128(W)×228.096(H) mm
Pixels1024(RGB)×768, XGA, 85PPI
Physical Size326.5(W)×253.5(H)×10(D) mm
Pixel ArrangementR.G.B. Vertical Stripe
Display Modea-Si TFT-LCD, LCM
Contrast Ratio1000:1
White Luminance ( Center )1000 cd/m2 (Typ.)  [cd/m2 ]
Optical Response Time30 (Typ.)(Tr+Td) ms
Nominal Input Voltage3.3 V (Typ.)
Frame Rate60Hz
Viewing Angle89/89/89/89 (Typ.)(CR≥10)
Weight [kg]0.93 kg
Interface Type20 pins   LVDS (1 ch, 8-bit)
Support Color16.7M, 72% NTSC
Surface TreatmentHard coating (3H),
RoHS ComplianceRoHS Compliance
Operating Temperature-20~70 °C
Storage Temperature-30~80 °C

RS150X0M-GE10 is a 15-inch LCD display with 1,000 nits brightness, 1024×768 resolution and 1000:1 contrast ratio. Its operating temperature range is -20 °C to 70 °C.

RisingStar RS150X0M-GE10 is a high brightness display that offer very high quality images and can be read even under sunlight, it is idea for outdoor device, such as marine, military, and industrial application.

RS150X0M-GE10 Main Features:

1. Original TFT LCD panel

2. High resolution: 1024(RGB)×768, XGA, 85PPI

3. Brightness up to 1000 nits

4.Military grade, Blackening Defect free

5. More brightness adjustment available: Auto brightness sensor, Manual brightness adjustment( PWM brightness adjustment, OSD brightness adjustment)

6. Multi touch (PCAP) is option.

1000nits high brightness

Risingstar RS150X0M-GE10 is 15 inches and boasting an impressive brightness level of 1000nits can be comfortably viewed even in broad daylight. The display has an added advantage of an auto-brightness control feature that ensures optimal brightness levels at all times. A built-in light sensor detects ambient lighting conditions and adjusts image brightness accordingly, providing users with an unrivaled viewing experience. This functionality also helps in cost-saving by reducing energy consumption, heat output, and prolongs the lifespan of the display.

True industrial Grade LCD IPS panel

Thanks to their special sunlight readable LCD panels technology, these displays can withstand surface temperatures up to 110 degree without suffering from any blackening defect. This is crucial for outward-facing window displays, which must contend with exposure to direct sunlight.

is a Wide Temperature,High Brightness,1024*768 TFT LCD monitor, WLED Backlight,Life ≥ 100K hours,With LED Driver,with LVDS interface. and Wide Operational Operating Temperature -20 ~ 70 °C

Product FAQs

How bright is the RS150X0M-GE10?

It is rated at 1,000 nits (cd/m²) brightness.

What are the main display specifications?

It uses a 15-inch panel, 1024×768 resolution, 1000:1 contrast ratio.

What is the operating temperature range?

The operating temperature range is -20 °C to 70 °C.

Is this product available for OEM or ODM customization?

Yes. RisingStar is an OEM/ODM manufacturer and accepts customization requirements for volume orders; contact the sales team with your target specification.

What interface does the RS150X0M-GE10 use?

It adopts 20 pins LVDS (1 ch, 8-bit) interface.

What is the power input requirement for the RS150X0M-GE10?

The power input requirement is 3.3 V (Typ.).

What is the viewing angle?

The viewing angle is 89/89/89/89 (Typ.)(CR≥10).

Is the RS150X0M-GE10 suitable for outdoor or high-ambient-light use?

Yes. Rated at 1,000 nits, it is a high-brightness panel built for sunlight-readable and outdoor applications.

How is the screen surface treated?

The panel surface treatment is Hard coating (3H),.

What panel technology does the RS150X0M-GE10 use?

It uses a-Si TFT-LCD, LCM.
