Specifications
| Screen Diagonal | 31.5 inch |
| panel no | RS315DJJ-NE10 |
| Brand | Risingstar |
| Model No | RS315DJJ-NE10 |
| Active Area | 698.4(H)X 392.85(V) |
| Resolution | 3840(RGB)×2160, UHD, 139PPI |
| Physical Size | 731.1(W)×425.7(H)×32.9(D) mm |
| Pixel Arrangement | R.G.B. Vertical Stripe |
| Display Mode | a-Si TFT-LCD, LCM |
| Contrast Ratio | 3000:1 |
| White Luminance ( Center ) | 1000 cd/m2 (Typ.) [cd/m2 ] |
| Optical Response Time | 9.5 (Typ.)(G to G) ms |
| Nominal Input Voltage | 12 V (Typ.) |
| Frame Rate | 60Hz |
| Viewing Angle | 89/89/89/89 (Typ.)(CR≥10) |
| Weight [g] | 6.6kgs |
| Interface Type | 51 pins V-by-One 8 lane, |
| Support Color | 1.07B, 79% NTSC |
| Surface Treatment | Matte (Haze 25%), Hard coating (3H) |
| RoHS Compliance | RoHS Compliance |
| Operating Temperature | -20~70 °C |
| Storage Temperature | -30~80 °C |
RS315DJJ-NE10 is a 31.5-inch LCD display with 1,000 nits brightness, 3840×2160 resolution and 3000:1 contrast ratio. Its operating temperature range is -20 °C to 70 °C.
RS315DJJ-NE10 high brightness TFT LCD display has a 3840* 2160 ultra high resolution, wide view 178×178 angle, it can easily captivates customers with its vivid image quality and quiet operation, it can helps business enhance thier brand image while enriching the customer's shopping experinece. The customized brightness are option: 500nits, 800nits, 1000nits, and 1500nits.
RS315DJJ-NE10 high brightness TFT LCD Main Features:
Resolution: 3840x2160 (UHD) 59PPI,
High Brightness: 1000 nits with auto-light sensor.
wide viewing angles: 178° veiw angle
7*24 hours working uninterrupted
support Landscape & portrait Installation way
1000nits High Brightness,
Image’s high brightness is a highly desired feature in a strong sunlight situation, thanks to this attribute, our displayed contents is fully readable, displays with high brightness may be successfully used e.g in expositions, buses station, digital signage or other outdoor application.
4K Ultra HD resolution.
The 4K Ultra HD picture quality ensures great colour and rich details in all possible broadcasting surroundings, ranging from retail stores, to restaurants and office buildings.
Landscape & portrait
Both landscape and portrait orientations are possible, providing you with endless creative and functional possibilities to fulfill your commercial or informative goals
Product FAQs
How bright is the RS315DJJ-NE10?
It is rated at 1,000 nits (cd/m²) brightness.
What are the main display specifications?
It uses a 31.5-inch panel, 3840×2160 resolution, 3000:1 contrast ratio.
What is the operating temperature range?
The operating temperature range is -20 °C to 70 °C.
Is this product available for OEM or ODM customization?
Yes. RisingStar is an OEM/ODM manufacturer and accepts customization requirements for volume orders; contact the sales team with your target specification.
What interface does the RS315DJJ-NE10 use?
It adopts 51 pins V-by-One 8 lane, interface.
What is the power input requirement for the RS315DJJ-NE10?
The power input requirement is 12 V (Typ.).
What is the viewing angle?
The viewing angle is 89/89/89/89 (Typ.)(CR≥10).
Is the RS315DJJ-NE10 suitable for outdoor or high-ambient-light use?
Yes. Rated at 1,000 nits, it is a high-brightness panel built for sunlight-readable and outdoor applications.
How is the screen surface treated?
The panel surface treatment is Matte (Haze 25%), Hard coating (3H).
What panel technology does the RS315DJJ-NE10 use?
It uses a-Si TFT-LCD, LCM.
