86inch floor standing window facing full screen display
OEM / ODM Manufacturer
Factory Direct
Order & Lead Time
Need 50+ units? for framework agreements.
Global Shipping Options
Samples ship in ~10 working days; Bulk orders in 15-25 working days.
- Express: DHL/FedEx door-to-door delivery (5-7 days)
- Sea Freight: Cost-optimized bulk shipping (30-45 days)
- Rush Orders: Available upon request for urgent projects
1-3 Year Standard Warranty
3 years for Display Units and 1 year for LCD modules. Extendable to 5 years. Includes 24/7 support, remote troubleshooting, and long-term spare parts availability.
All products are manufactured in our ISO 9001-certified facility.
CE, FCC, RoHS Certified
86inch floor standing window facing full screen display General Description
RS860ENT-N07 floor standing window facing full screen display are assembled with Grade a+ panel, well protected by with tempered glass and galvanized steel plate. Full screen, with great gold raito 8:3, plug and play, auto-ligh sensor, intelligent thermal management, lower power consumption, vandal-proof, dust-proof, waterproof, ultraviolet-proof, floor standing are the main features. They are ideally suited to a number of applications including bus / train stations, airports, and retail store windows. As most of the window facing displays are need to be customized, RisingLCD can meet your request in the various designs and appearance.
86inch floor standing window facing full screen display Main Features:
Panel: Original Grade A+ panel.
Resolution: 3840x1440,
High Brightness: 400-700 nits with auto-light sensor.
wide viewing angles: 178° veiw angle
OS: Windows or Android.
Color: black, gray, white, red, golden, shining silver…
Support 24 hours, 365days non-stop display
Installation way: Floor standing, mounted wall or hanging celling are all available.
HD wide viewing angle, HD display,
Full HD display panel, anti-glare, giving your different visual enjoyment from different angles from top to bottom, from left to right.

Plug and play
Automatic circulation of advertisements, Insert the USB flash disk or SD card to automatically recongize the contents of the usb flash disk for play back

OEM and ODM are welcomed!
RisingLCD is a professional highlight LCD manufacturer from China, specializes in manufacturing and distributing all types of LCD module, LCD monitors, outdoor and indoor digital signage and goods are exported all of the world, could customize the products based on the customer needs with a competitive price, RisingLCD is your best choice!
| specification Parameter | |
| Item No | RS860ENT-N07 |
| Size | 86 inch |
| Display Area | 1895*710mm |
| Brightness | 400-700nits |
| Resolution | 3840*1440 |
| Aspect Ratio | 8:03 |
| Response Time | 6/9 (Typ.)(Tr/Td) ms |
| View Angle | 89/89/89/89 (Min.)(CR≥10) |
| LED | DLED |
| Lifetime | 50000H |
| Intelligent dimming | Support |
| Intelligent temperature control | Support |
| Remote Control | Support |
| Input Voltage | AC90-264V,50/60HZ |
| Shell Material | Metal Plate |
| Product Dimensions | 2020*771*75.5mm |
| Package size: | 2085*205*890mm(L*W*J) |
| environmental conditions | Semi-outdoor |
| Operating temperature & humidity | -20 ~ 70 °C |
| Main-board | Android /PC/ HD Driver Board (Optional) |
| IO interface | HDMI/VGA/DVI/USB/RJ45 |
01 / Chassis & Materials
Structural integrity for extreme environments.
| Enclosure Grade | Medical and Food grade SUS316L Stainless Steel, AL5052 Aluminum, or SECC Galvanized Steel. |
| Protection Rating | Certified IP65 / IP69K waterproof sealing. Mechanical impact protection rated at IK10. |
| Surface Finish | Industrial powder coating (RAL spectrum), sandblasting, and anti-acid marine painting. |
| Format Architecture | Chassis-mount, Open-frame, Panel-mount, and VESA-integrated configurations. |
03 / Interface & I/O
Industrial signal and power regulation.
| Connectors | Support for M12 Aviation Circular Connectors, DB9/RS232, and waterproof RJ45/USB. |
| Power Regulation | Wide voltage DC 9V - 36V input with integrated surge and polarity protection. |
| Sensor Suite | Integrated ambient light sensors, thermal probes, and custom GPIO control protocols. |
02 / Optical & Display
Visibility optimization for extreme ambient lighting.
| Luminance Output | Scalable 1500 - 5000 Nits with integrated Hi-Tni (110°C) anti-blackening technology. |
| Optical Bonding | Full Vacuum Optical Bonding (OCR) — eliminates air gaps, fogging, and maximizes contrast ratio. |
| Advanced Coating | Integrated AR (Anti-Reflective), AG (Anti-Glare), and AF (Anti-Fingerprint) nano-films. |
04 / Embedded & Data
Software architecture and data sync.
| Operating Systems | Full compatibility with Windows 7, 10/11 IoT; Linux support covering the last 3 generations (Ubuntu 20.04, 22.04, 24.04 LTS) and Debian; as well as comprehensive support for Android 11 through 14. |
| Communication | High-speed 4G/5G LTE modules, Dual-band Wi-Fi 6, and Gigabit Ethernet. |
