    RisingLCD model name RS220ENT-N10

    2021-10-25 09:39:00  News

    Rectangle: Rectangle



    RGB Vertical Stripe:

    RGBW Rectangle: Red green blue white square < BR />RG/BW PenTile: (Red green)(blue and white) Vertical stripes < BR />RG/BG PenTile: (red green)(blue and green) Vertical stripes < BR />RGBY Vertical Stripe: Red, green, blue and yellow



    Display dimensions 473.76 x 296.1 mm (H x V) Exterior dimensions 493.7 x 320.1 x 15.75 mm (H x V x D)



    Visible size 477.7 × 300.1 mm (H×V) Surface treated fog surface, Hard coating (3H)



    Luminance (CD /m²)1000 (Typ.) to 2000:1 (Typ.) [transmission]



    < BR />IPS Hard screen series: AAS, ADS, AHVA, FFS, IPS, New Mode2, PLS, SFT, Vistarich ASV, HVA, MVA, PVA, SVA, UV squared A, VA



    Visual Angle of 89/89/89/89 (Typ.) (CR 10 or higher) response speed 15/5 (Typ.) (Tr/Td); 8 (Typ.)(G to G) ms



    Color quantity 16.7m, 70% NTSC backlight type WLED, 30K hours, including LED driver



    Screen weight 2.10Kgs (Typ.) for industrial games



    Refresh frequency 60Hz

    120Hz (input 60Hz) : built-in MEMC circuit

    120Hz+120Hz: 120Hz panel +120Hz backlight

    240Hz (input 60Hz) : built-in MEMC circuit touch function none touch



    Signal system LVDS (2 CH, 8-bit), terminal, 30 pins



    Supply voltage 5.0V (Typ.)



    Maximum rated storage temperature: -20 to 60 °C Operating temperature: 0 to 50 °C
