Risinglcd 700 nits bus station information monitor manufacturer

Bus stop information LCD monitor, outdoor applications require a minimum of 700 nits for sunlight readable, industrial design, 21.5 inches, compatible with windows, Android, and Raspberry Pi, HDMI/USB/HDMI/SDI/VGA/DVI, Other interfaces provide customization,

700 to 2000 nits, you can choose, the brightness is automatically adjusted,

Brand: RISINGLCD Model Name: G215ENT-N07

Screen size: 21.5 inches Screen type: LCD module, a-Si TFT-LCD

Resolution: 1920(RGB)×1080 Pixel configuration: RGB vertical bar

Display size: 476.064×267.786 mm (H×V) Appearance size: 501.1×292.2×16.12 mm (H×V×D)

Visual size: 480.7×271.8 mm (H×V) Surface treatment: matte, Hard coating (3H)

Brightness: 700 nits Contrast degree: 1400: 1

Best angle: full viewing angle Optical mode: AHVA, normally black display, transmissive

Viewing angle: 89/89/89/89 Response speed: 25 ms

Number of colors: 16.7M, 72% NTSC backlight type: 4 strings×2CN WLED, 50K hours, no driver

Screen weight: 2.10Kgs Suitable for: digital signage outdoor highlight

Refresh rate: 60Hz

Signal system: LVDS (2 ch, 8-bit), terminal, 30 pins

Supply voltage: 5.0V

Maximum rating: Storage temperature: -20 ~ 95 °C Working temperature: -20 ~ 95 °C

Wide temperature design, industrial-grade LCD panel, provide third-party test report and high temperature test video, provide ROHS certification.
