RisingStar introduces a 29.4-inch high brightness TFT-LCD passenger information display, specifically engineered for the demands of modern railway environments. Utilizing an a-Si TFT-LCD panel with an ultra-wide resolution of 1920×720 and a crisp 69PPI, this display delivers exceptional clarity and readability in all lighting conditions. Its AMVA3 wide-viewing technology (89° in all directions) ensures passengers can easily access critical information from any angle.
With brightness options ranging from 500nits to 5000nits, this screen remains sunlight readable even in the harshest outdoor conditions—ideal for platform and onboard installations. The panel features a contrast ratio of 4000:1 (Typ.), 16.7M color depth, and 72% NTSC coverage for vivid, high-contrast visuals. Designed with a matte finish and 3H hard coating, the display reduces glare and resists surface damage.
Engineered for reliability and low power consumption, this WLED-backlit module boasts a 70,000-hour lifespan and includes an integrated LED driver. It supports 60Hz operation and is equipped with built-in MEMC circuitry for smoother video performance up to 240Hz. With a robust structure weighing just 3.7kg, the 29.4" display fits easily into railway systems with its wide cut-bar aspect and thin profile. Signal input is supported via LVDS (2 channel, 8-bit, 51 pins), powered at 12V.
Application Areas:
Railway and metro station platforms
Passenger train carriages
Light rail vehicles and intercity trains
Bus rapid transit (BRT) and EV charging kiosks
Smart city outdoor signage solutions
Digital advertising in public transportation environments
Commercial Value:
This 29.4-inch passenger information display significantly enhances operational efficiency and user experience in public transport systems. Its high brightness and all-angle visibility ensure critical travel information, safety messages, and real-time updates are accessible under any conditions. For railway operators, it offers a robust and long-life display solution that reduces maintenance costs, supports dynamic content delivery, and improves passenger satisfaction. As cities continue to adopt intelligent transportation systems, this panel positions itself as a smart, future-ready investment for both public and commercial deployments.
| Item | Description |
|---|---|
| Panel Size | 29.4 inch |
| Panel Type | a-Si TFT-LCD, Transmissive, AMVA3 Technology |
| Resolution | 1920 (RGB) × 720 |
| Pixel Density | 69 PPI |
| Pixel Configuration | RGB Vertical Stripe |
| Active Area | 698.4 (W) × 261.9 (H) mm |
| Bezel Opening | 702.4 (W) × 256.9 (H) mm |
| Surface Treatment | Anti-glare (Haze 28%), Hard Coating (3H) |
| Brightness (Typ.) | 2500 / 3000 / 4000 / 5000 nits |
| Contrast Ratio | 4000:1 (Typ.) |
| Viewing Angle | 89°/89°/89°/89° (L/R/U/D, CR≥10) |
| Display Mode | Normally Black, Wide Viewing, Transmissive |
| Response Time | 8 ms (Typ., G to G) |
| Display Colors | 16.7M (72% NTSC) |
| Backlight Type | WLED, Lifetime: 70,000 hours, Integrated LED Driver |
| Refresh Rate | 60Hz (Input), MEMC Support up to 120Hz or 240Hz |
| Touch Function | None |
| Panel Weight | 3.7 kg (Typ.) |
| Signal Interface | LVDS (2 ch, 8-bit), 51 pins |
| Power Supply | 12V (Typ.) |
| Operating Temp. | 0°C to 50°C |
| Storage Temp. | -20°C to 60°C |
| Applications | Railway, Metro, BRT, EV Kiosks, Smart Transit Systems |
| Item | Description |
|---|---|
| Panel Size | 29.4 inch |
| Panel Type | a-Si TFT-LCD, Transmissive, AMVA3 Technology |
| Resolution | 1920 (RGB) × 720 |
| Pixel Density | 69 PPI |
| Pixel Configuration | RGB Vertical Stripe |
| Active Area | 698.4 (W) × 261.9 (H) mm |
| Bezel Opening | 702.4 (W) × 256.9 (H) mm |
| Surface Treatment | Anti-glare (Haze 28%), Hard Coating (3H) |
| Brightness (Typ.) | 2500 / 3000 / 4000 / 5000 nits |
| Contrast Ratio | 4000:1 (Typ.) |
| Viewing Angle | 89°/89°/89°/89° (L/R/U/D, CR≥10) |
| Display Mode | Normally Black, Wide Viewing, Transmissive |
| Response Time | 8 ms (Typ., G to G) |
| Display Colors | 16.7M (72% NTSC) |
| Backlight Type | WLED, Lifetime: 70,000 hours, Integrated LED Driver |
| Refresh Rate | 60Hz (Input), MEMC Support up to 120Hz or 240Hz |
| Touch Function | None |
| Panel Weight | 3.7 kg (Typ.) |
| Signal Interface | LVDS (2 ch, 8-bit), 51 pins |
| Power Supply | 12V (Typ.) |
| Operating Temp. | 0°C to 50°C |
| Storage Temp. | -20°C to 60°C |
| Applications | Railway, Metro, BRT, EV Kiosks, Smart Transit Systems |
Ask a quote for the latest price and one of our team members will respond as soon as possible.
