65 inch 2500 nits high brightness TFT LCD panel for passenger information display

65 inch 2500 nits high brightness TFT LCD panel for passenger information display

BrandRisingstar
Model No.RS650EQC-ND25
Screen Size65 inch
Resolution3840*2160
Brightness2500 cd/m²
Panel TypeLG A-Grade Open Cell
ApplicationPassenger Information Display
FeaturesSunlight readable
Overview Specifications Customized Services Support & Shipping

The RS650EQC-ND25 is a high-brightness LCD panel featuring 2,500 nits brightness, ultra-high 4K resolution (3840*2160), and a 1300:1 contrast ratio. With a wide viewing angle of 89/89/89/89 (Min.)(CR≥10) and a 60Hz refresh rate, this display is engineered for mission-critical Passenger Information Display Systems (PIDS) in bus stations, railway terminals, and airports.

65-inch High Brightness TFT LCD Panel Main Features:

Up to 5,000 nits brightness available, ensuring direct sunlight readability.

Full size range from 7 to 100 inches for versatile deployment.

Industrial Hi-Tni technology prevents blackening defects under intense solar radiation.

Up to 4K UHD resolution for crystal-clear imagery.

Noise-less and space-efficient thermal management design.

Automatic brightness control for optimized visibility and energy efficiency.

Supports both landscape and portrait orientation.

2,500 Nits High Brightness

The RS650EQC-ND25 TFT LCD panel utilizes an industrial-grade LED backlight to deliver 2,500 nits brightness with high-contrast picture quality and low power consumption. Specifically designed for sunlight-readable passenger information displays, these panels are equipped with Tier-1 Grade A open cells (LG Display) to ensure your content stands out vividly in any high-ambient commercial location.

65-inch High Brightness TFT Panel Applications:

Public transit hubs (Bus, Rail, and Airport PIDS), high-speed train information screens, large retail shop windows, car dealerships, hospitality venues, and smart city kiosks.

RS650EQC-ND25 65 inch high brightness display 65 inch sunlight readable LCD High brightness display Sunlight readable display Outdoor waterproof display
Screen Diagonal65 inch
Brand Risingstar
Model NoRS650EQC-ND25
Active Area1428.48(W)×803.52(H) mm
Resolution3840(RGB)×2160, UHD, 68PPI
Physical Size1461（H）*843.1(V)*60.3(D)mm
Pixel ArrangementR.G.B. Vertical Stripe
Display Modea-Si TFT-LCD, LCM
Contrast Ratio :1300:1
White Luminance ( Center )2500 cd/m2 (Typ.)  [cd/m2 ]
Optical Response Time8/10 (Typ.)(Tr/Td) ms
Nominal Input Voltage12.0V (Typ.)
Frame Rate60Hz
Viewing Angle89/89/89/89 (Typ.)(CR≥10)
Weight [kg]20.5(Typ.)
Interface Type120 pins   EPI  connector
Support Color1.07B ,
Surface TreatmentAntiglare (Haze 3%), Hard coating (2H)
RoHS ComplianceRoHS Compliance
Temperature Range-20 ~70 °C
Storage (Non-Operating)-30 ~ 80 °C
inventory_2

01 / Chassis & Materials

Structural integrity for extreme environments.

Enclosure Grade

Medical and Food grade SUS316L Stainless Steel, AL5052 Aluminum, or SECC Galvanized Steel.

Protection Rating

Certified IP65 / IP69K waterproof sealing. Mechanical impact protection rated at IK10.

Surface Finish

Industrial powder coating (RAL spectrum), sandblasting, and anti-acid marine painting.

Format Architecture

Chassis-mount, Open-frame, Panel-mount, and VESA-integrated configurations.

blur_on

02 / Optical & Display

Visibility optimization for extreme ambient lighting.

Luminance Output

Scalable 1500 - 5000 Nits with integrated Hi-Tni (110掳C) anti-blackening technology.

Optical Bonding

Full Vacuum Optical Bonding (OCR) - eliminates air gaps, fogging, and maximizes contrast ratio.

Advanced Coating

Integrated AR (Anti-Reflective), AG (Anti-Glare), and AF (Anti-Fingerprint) nano-films.

settings_input_component

03 / Interface & I/O

Industrial signal and power regulation.

Connectors

Support for M12 Aviation Circular Connectors, DB9/RS232, and waterproof RJ45/USB.

Power Regulation

Wide voltage DC 9V - 36V input with integrated surge and polarity protection.

Sensor Suite

Integrated ambient light sensors, thermal probes, and custom GPIO control protocols.

dns

04 / Embedded & Data

Software architecture and data sync.

Operating Systems

Full compatibility with Windows 7, 10/11 IoT; Linux support covering the last 3 generations (Ubuntu 20.04, 22.04, 24.04 LTS) and Debian; as well as comprehensive support for Android 11 through 14.

Communication

High-speed 4G/5G LTE modules, Dual-band Wi-Fi 6, and Gigabit Ethernet.

Sampling
10-15 Working Days
Standard
SUS316L / IP69K
Certifications
CE / FCC / UKCA
Response
8H Expert Team
verified

01 / Warranty Policy

Industry-leading protection for your investment.

Complete System

3 Years Full Warranty for the complete machine assembly.

LCD Module

1 Year Warranty for the original LCD assembly.

Extended Support

Optional extended warranty programs (up to 5 years) available upon request.

support_agent

02 / Field Support

Expert guidance throughout the product lifecycle.

Remote Assistance

24/7 technical support and configuration guidance via video link or remote access.

On-site Services

Local on-site installation and maintenance available for large-scale deployments.

schedule

03 / Production Timeline

Scalable manufacturing for urgent project schedules.

Sample Prototyping

Verification and custom prototype delivery within 10 Working Days.

Bulk Production

Standard bulk order fulfillment in 15 - 25 Working Days.

public

04 / Global Distribution

Reliable logistics via air, sea, or rail.

Express & Air

Door-to-door global delivery in 5 - 7 Working Days (DHL, FedEx, UPS).

Ocean & Rail

Cost-optimized bulk shipping in 30 - 45 Days for global major ports.
