With the feature of 1000nits high brightness, clear resolution and rich depth, the LCD display could let you see a vivid world, this display could make you see the real image even under the sun.
These rugged LCD display are rigorously tested to ensure compliance with various industry standards and are ideal for use in any high ambient light condition, and and will give you the intensity and brilliance your application requires.
RS121TD02-GE10 main features
True Industrial a Grade LCD Panel
3. 1000 nits (cd/m2) sunlight readable Brightness
Long-Life Advanced LED Backlight, over 100,000 Hours Half-Life
Smart Brightness Control Exceptional Contrast for Improved Sunlight Readability
Wide Operational Temperature Range -30°C to 80°C (-22°F to 185°F)
Touch Screen Technologies Available (Optional)
High brightness
RisingLCD 12.1 inch industrial LCD is boasting an impressive brightness level of 1000nits can be comfortably viewed even in broad daylight. The display has an added advantage of an auto-brightness control feature that ensures optimal brightness levels at all times.
True industrial Grade LCD IPS panel
Thanks to their special sunlight readable LCD panels technology, these displays can withstand surface temperatures up to 110 degree without suffering from any blackening defect. This is crucial for outward-facing window displays, which must contend with exposure to direct sunlight.
| Screen Diagonal | 12.1 inch |
| Brand | Risingstar |
| Model No | RS121TD02-GE10 |
| Active Area | 261.12(W)×163.2(H) mm |
| Resolution | 1280(RGB)×800, WXGA, 124PPI |
| Physical Size | 283(W)×185.1(H)×10.2(D) mm |
| Pixel Arrangement | R.G.B. Vertical Stripe |
| Display Mode | a-Si TFT-LCD, LCM |
| Contrast Ratio : | 700:1 |
| White Luminance ( Center ) | 1000 nits |
| Optical Response Time | 4/12 (Typ.)(Tr/Td) ms |
| Nominal Input Voltage | 3.3V (Typ.) |
| Frame Rate | 60Hz |
| Viewing Angle | 80/80/80/60 (Typ.)(CR≥10) |
| Weight [g] | 620g(Typ.) |
| Interface Type | LVDS (1 ch, 6/8-bit) , 20 pins |
| Support Color | 262K/16.7M , 40% NTSC |
| Surface Treatment | Antiglare,Hard coating (2H) |
| RoHS Compliance | RoHS Compliance |
| Temperature Range | -30 ~80 °C |
| Storage (Non-Operating) | -30 ~ 80 °C |
Ask a quote for the latest price and one of our team members will respond as soon as possible.
