43" Stretched TFT LCD panel for passenger information display
OEM / ODM Manufacturer
Factory Direct
Order & Lead Time
Need 50+ units? for framework agreements.
Global Shipping Options
Samples ship in ~10 working days; Bulk orders in 15-25 working days.
- Express: DHL/FedEx door-to-door delivery (5-7 days)
- Sea Freight: Cost-optimized bulk shipping (30-45 days)
- Rush Orders: Available upon request for urgent projects
1-3 Year Standard Warranty
3 years for Display Units and 1 year for LCD modules. Extendable to 5 years. Includes 24/7 support, remote troubleshooting, and long-term spare parts availability.
All products are manufactured in our ISO 9001-certified facility.
CE, FCC, RoHS Certified
RisingStar RS430IVN-GD30 – Specification Table
| Item | Specification |
|---|---|
| Screen Diagonal | 43 inch |
| Brand | RisingStar |
| Model No. | RS430IVN-GD30 |
| Active Area (mm) | 1073.78 (W) × 201.335 (H) |
| Pixels | 1920 (RGB) × 360, 45 PPI |
| Physical Size (mm) | 1107.4 (W) × 239.9 (H) × 54.1 (D) |
| Pixel Arrangement | RGB Vertical Stripe |
| Display Mode | a-Si TFT-LCD, LCM |
| Contrast Ratio | 4000:1 |
| White Luminance (Center) | 500 ~ 3000 nits |
| Optical Response Time | 16 ms (Typ., Tr+Td) |
| Nominal Input Voltage | 12V (Typ.) |
| Frame Rate | 60Hz |
| Viewing Angle (CR≥10) | 89/89/89/89 |
| Weight | 5.2 kg |
| Interface Type | 51-pin LVDS (2-ch, 8-bit) |
| Supported Colors | 16.7M, 60% NTSC |
| Surface Treatment | Hard coating (3H) |
| Power Consumption | 138W |
| RoHS Compliance | Yes |
| Operating Temperature | -20 ~ 70 °C |
| Storage Temperature | -30 ~ 80 °C |
Description
The RisingStar RS430IVN-GD30 is a 43-inch industrial-grade stretched LCD panel designed for demanding outdoor and semi-outdoor digital signage. Featuring a 1073.78 × 201.335 mm ultra-wide active area, 4000:1 contrast ratio, and 500–3000 nits high brightness, it delivers exceptional sunlight readability and visual clarity.
The panel uses a 51-pin LVDS interface, supports 16.7M colors, and operates reliably in extreme environments from –-20 ~ 70 °C. With a robust 3H hard-coated surface and a slim, durable structure, it is suitable for long-life applications requiring 24/7 operation.
Application Scenarios
This 43-inch high-brightness stretched LCD is ideal for:
• Passenger Information Display (PID)
Used in railways, buses, metros, and airport terminals for schedule boards, arrival messages, and dynamic advertising.
• Outdoor Digital Signage
Perfect for outdoor kiosks, bus shelters, EV charging stations, and fuel pumps where strong sunlight readability is essential.
• Retail & Wayfinding
Suitable for ultra-wide shelf displays, menu boards, directional signage, and smart store display systems.
• Industrial & Commercial Systems
Compatible with machine interfaces, control systems, and industrial automation requiring a high-reliability display.
| Screen Diagonal | 43 inch |
| Brand | RisingStar |
| Model No | RS430IVN-GD30 |
| Active Area | 1073.78(W)×201.335(H) mm |
| Pixels | 1920(RGB)×360, 45PPI |
| Physical Size | 1107.4（H）*239.9(V)*54.1(D) |
| Pixel Arrangement | R.G.B. Vertical Stripe |
| Display Mode | a-Si TFT-LCD, LCM |
| Contrast Ratio : | 4000:1 |
| White Luminance ( Center ) | 500~3000nits |
| Optical Response Time | 16 (Typ.)(Tr+Td) ms |
| Nominal Input Voltage | 12V (Typ.) |
| Frame Rate | 60Hz |
| Viewing Angle | 89/89/89/89 (Typ.)(CR≥10) |
| Weight [g] | 5.2 kgs |
| Interface Type | 51 pins LVDS (2 ch, 8-bit) |
| Support Color | 16.7M , 60% NTSC |
| Surface Treatment | Hard coating (3H), |
| Power consumption | 138W |
| RoHS Compliance | RoHS Compliance |
| Operating Temperature | -20 ~ 70 °C |
| Storage Temperature | -30 ~ 80 °C |
01 / Chassis & Materials
Structural integrity for extreme environments.
| Enclosure Grade | Medical and Food grade SUS316L Stainless Steel, AL5052 Aluminum, or SECC Galvanized Steel. |
| Protection Rating | Certified IP65 / IP69K waterproof sealing. Mechanical impact protection rated at IK10. |
| Surface Finish | Industrial powder coating (RAL spectrum), sandblasting, and anti-acid marine painting. |
| Format Architecture | Chassis-mount, Open-frame, Panel-mount, and VESA-integrated configurations. |
03 / Interface & I/O
Industrial signal and power regulation.
| Connectors | Support for M12 Aviation Circular Connectors, DB9/RS232, and waterproof RJ45/USB. |
| Power Regulation | Wide voltage DC 9V - 36V input with integrated surge and polarity protection. |
| Sensor Suite | Integrated ambient light sensors, thermal probes, and custom GPIO control protocols. |
02 / Optical & Display
Visibility optimization for extreme ambient lighting.
| Luminance Output | Scalable 1500 - 5000 Nits with integrated Hi-Tni (110°C) anti-blackening technology. |
| Optical Bonding | Full Vacuum Optical Bonding (OCR) — eliminates air gaps, fogging, and maximizes contrast ratio. |
| Advanced Coating | Integrated AR (Anti-Reflective), AG (Anti-Glare), and AF (Anti-Fingerprint) nano-films. |
04 / Embedded & Data
Software architecture and data sync.
| Operating Systems | Full compatibility with Windows 7, 10/11 IoT; Linux support covering the last 3 generations (Ubuntu 20.04, 22.04, 24.04 LTS) and Debian; as well as comprehensive support for Android 11 through 14. |
| Communication | High-speed 4G/5G LTE modules, Dual-band Wi-Fi 6, and Gigabit Ethernet. |
