RS430NET-N20 43 inch 2000nits wall mount LCD display for outdoor advertising
OEM / ODM Manufacturer
Factory Direct
Order & Lead Time
Need 50+ units? for framework agreements.
Global Shipping Options
Samples ship in ~10 working days; Bulk orders in 15-25 working days.
- Express: DHL/FedEx door-to-door delivery (5-7 days)
- Sea Freight: Cost-optimized bulk shipping (30-45 days)
- Rush Orders: Available upon request for urgent projects
1-3 Year Standard Warranty
3 years for Display Units and 1 year for LCD modules. Extendable to 5 years. Includes 24/7 support, remote troubleshooting, and long-term spare parts availability.
All products are manufactured in our ISO 9001-certified facility.
CE, FCC, RoHS Certified
1920*1080,43 inch 2000nits wall mount display for outdoor advertising,Waterproof IP56-IP66 optional, resistant enough to be mounted outside,
Outdoor advertising machine series of products are using professional and unique ultra high brightness LED backlight modular heat dissipation module design, and the latest international outdoor technology, with the most simple technical design concept to achieve the most stable high-performance products. To achieve excellent optical display characteristics, good body thermal conductivity and ultra-high product reliability, whether in the hot and high temperature environment of strong sunlight direct exposure to the screen surface for a long time, or in the environment as low as -20°C, can meet the long-term stable work and display bright colors and clear images. It is the LCD with excellent brightness stability using LED backlight in similar products worldwide.
43inch waterproof lcd monitor has excellent characteristics and good reliability for use in harsh environment, and provides good convenience and quick matching for customers' equipment. Customers can complete the finished product through this module. Can be widely used in outdoor square, electronic platform, large supermarket chain stores, stadiums, airports and other outdoor environment media image playback.
Item | Description |
Product Dimension | 43inch |
Resolution | 1920*1080 |
Display Type | TFT-LCD |
Display ratio | 16:9 |
Brightness | 2000-5000nits(Auto brightness) |
Display color | 16.7M |
View angle | Horizontal 178°，Vertical 178° |
Respon Time | 6ms |
Constrast Ratio | 1400:1 |
Service life | up to 50,000 hoursours |
Backlight Type | WLED |
Input Votage | AC110V-240V 60HZ |
Power | 350W |
Texture of material | The shell of the whole machine is made of 2mm galvanized plate, and the surface is sprayed with outdoor powder |
Glass | 6mm ultra white high transparent explosion-proof toughened glass anti glare, anti reflection and light transmittance over 98%（AR,AC optional） |
Waterproof | IP56, |
Dustproof | Internal filter screen device |
Rust prevention and corrosion protection | High strength galvanized steel plate, outdoor powder surface treatment |
Cpu | RK3288 A20 + 4G network |
Memory | DDR3 2GB |
Built in memory | EMMC 8G,16G,32G |
Operating System | Android 4.4/5.0(Windows and stand-alone optional) |
OSD language | Default English for multiple languages |
Playback mode | It supports multiple playback modes such as loop, timing and insertion |
Network support | Ethernet, supporting WiFi and wireless peripheral expansion(3G/4G optional) |
Video playback | WMV、AVI、FLV、RM、RMVB、MPEG、TS、MP4、VOD、MOV、MKV、MP3,AAC ect |
Picture format | Support BMP,JPEG,PNG,GIF etc. |
Audio output | Support HDMI output,Left and right channel output 10W horn |
Software release | Support background publishing files, remote setting of automatic switch, remote volume increase and decrease |
Temperature control | Support temperature control, control fan speed at different temperatures |
Leakage protection | Support leakage protection switch |
Lightning protection | Built in over temperature and over current protection function for high-voltage DC power supply can provide class C surge |
Time control protection | Power switch control. can customized switch by day, week and month7/24 |
Brightness control | The built-in photosensitive probe can automatically adjust the brightness of LCD display screen according to the intensity of |
Cooling system | 1. Intelligent air cooling system is adopted for heat dissipation 2. Intelligent control of wind speed and energy saving of fan speed control board 3. It can meet the requirement of no blackening of LCD screen in the environment of - 30 ℃ to 110 ℃ |
01 / Chassis & Materials
Structural integrity for extreme environments.
| Enclosure Grade | Medical and Food grade SUS316L Stainless Steel, AL5052 Aluminum, or SECC Galvanized Steel. |
| Protection Rating | Certified IP65 / IP69K waterproof sealing. Mechanical impact protection rated at IK10. |
| Surface Finish | Industrial powder coating (RAL spectrum), sandblasting, and anti-acid marine painting. |
| Format Architecture | Chassis-mount, Open-frame, Panel-mount, and VESA-integrated configurations. |
03 / Interface & I/O
Industrial signal and power regulation.
| Connectors | Support for M12 Aviation Circular Connectors, DB9/RS232, and waterproof RJ45/USB. |
| Power Regulation | Wide voltage DC 9V - 36V input with integrated surge and polarity protection. |
| Sensor Suite | Integrated ambient light sensors, thermal probes, and custom GPIO control protocols. |
02 / Optical & Display
Visibility optimization for extreme ambient lighting.
| Luminance Output | Scalable 1500 - 5000 Nits with integrated Hi-Tni (110°C) anti-blackening technology. |
| Optical Bonding | Full Vacuum Optical Bonding (OCR) — eliminates air gaps, fogging, and maximizes contrast ratio. |
| Advanced Coating | Integrated AR (Anti-Reflective), AG (Anti-Glare), and AF (Anti-Fingerprint) nano-films. |
04 / Embedded & Data
Software architecture and data sync.
| Operating Systems | Full compatibility with Windows 7, 10/11 IoT; Linux support covering the last 3 generations (Ubuntu 20.04, 22.04, 24.04 LTS) and Debian; as well as comprehensive support for Android 11 through 14. |
| Communication | High-speed 4G/5G LTE modules, Dual-band Wi-Fi 6, and Gigabit Ethernet. |
