49.5 inch Open Frame High Brightness LCD Monitor

49.5 inch Open Frame High Brightness LCD Monitor

BrandRisingStar
Model nameRS495FNX01D01
Screen size49.5"
Screen typeStretched LCD
Resolution1920(RGB)×540
Brightness (cd/m²)4000
Overview Specifications Customized Services Support & Shipping

49

49.5" High Brightness Open Frame Monitor

Key Features

  • High brightness 4000 nits

  • Sunlight readable performance

  • LED backlight

  • Wide viewing angle: 178°(H) / 178°(V)

  • Wide operating temperature: -20 ~ 70 °C

  • LCD blacking defect free

  • Low power consumption

  • Backlight MTBF: 50,000 hours

  • Intelligent temperature control system with active heat dissipation

Specifications

ItemDetails
Model NameRS495FNX01D01
Screen Size49.5"
Display Area (mm)1018.8 (H) × 572.67 (V)
Brightness4000 cd/m²
Resolution1920 × 540
Aspect Ratio＜ 3 : 1
Contrast Ratio4000 : 1
Pixel Pitch (mm)0.630 (H) × 0.630 (V)
Viewing Angle89/89/89/89 (Min.) (CR ≥ 10)
Color Saturation (NTSC)72%
Display Colors16.7M
Response Time8 ms (Typ., Tr/Td)
Input InterfaceEARPHONE OUT ×1, AUDIO IN ×1, VGA ×1, DVI ×1, HDMI ×1, AC IN ×1
OSD KeysAUTO / MENU / LEFT / RIGHT / EXIT / SELECT / POWER
GlassN/A
Touch TypeN/A
Input PowerAC 200–240 V
Power ConsumptionTBD
Radiator SystemN/A
Dimensions (mm)1242.2 × 377.8 × 78
Mounting400 × 200 mm, Screws: M8
Weight (Net)TBD
Operating Temperature-20 ~ 70 °C
Storage Temperature-30 ~ 80 °C
RS495FNX01D01 49.5 inch high brightness display 49.5 inch sunlight readable LCD High brightness display Sunlight readable display Outdoor waterproof display

Specifications

ItemDetails
Model NameRS495FNX01D01
Screen Size49.5"
Display Area (mm)1018.8 (H) × 572.67 (V)
Brightness4000 cd/m²
Resolution1920 × 540
Aspect Ratio＜ 3 : 1
Contrast Ratio4000 : 1
Pixel Pitch (mm)0.630 (H) × 0.630 (V)
Viewing Angle89/89/89/89 (Min.) (CR ≥ 10)
Color Saturation (NTSC)72%
Display Colors16.7M
Response Time8 ms (Typ., Tr/Td)
Input InterfaceEARPHONE OUT ×1, AUDIO IN ×1, VGA ×1, DVI ×1, HDMI ×1, AC IN ×1
OSD KeysAUTO / MENU / LEFT / RIGHT / EXIT / SELECT / POWER
GlassN/A
Touch TypeN/A
Input PowerAC 200–240 V
Power ConsumptionTBD
Radiator SystemN/A
Dimensions (mm)1242.2 × 377.8 × 78
Mounting400 × 200 mm, Screws: M8
Weight (Net)TBD
Operating Temperature-20 ~ 70 °C
Storage Temperature-30 ~ 80 °C
inventory_2

01 / Chassis & Materials

Structural integrity for extreme environments.

Enclosure Grade

Medical and Food grade SUS316L Stainless Steel, AL5052 Aluminum, or SECC Galvanized Steel.

Protection Rating

Certified IP65 / IP69K waterproof sealing. Mechanical impact protection rated at IK10.

Surface Finish

Industrial powder coating (RAL spectrum), sandblasting, and anti-acid marine painting.

Format Architecture

Chassis-mount, Open-frame, Panel-mount, and VESA-integrated configurations.

blur_on

02 / Optical & Display

Visibility optimization for extreme ambient lighting.

Luminance Output

Scalable 1500 - 5000 Nits with integrated Hi-Tni (110掳C) anti-blackening technology.

Optical Bonding

Full Vacuum Optical Bonding (OCR) - eliminates air gaps, fogging, and maximizes contrast ratio.

Advanced Coating

Integrated AR (Anti-Reflective), AG (Anti-Glare), and AF (Anti-Fingerprint) nano-films.

settings_input_component

03 / Interface & I/O

Industrial signal and power regulation.

Connectors

Support for M12 Aviation Circular Connectors, DB9/RS232, and waterproof RJ45/USB.

Power Regulation

Wide voltage DC 9V - 36V input with integrated surge and polarity protection.

Sensor Suite

Integrated ambient light sensors, thermal probes, and custom GPIO control protocols.

dns

04 / Embedded & Data

Software architecture and data sync.

Operating Systems

Full compatibility with Windows 7, 10/11 IoT; Linux support covering the last 3 generations (Ubuntu 20.04, 22.04, 24.04 LTS) and Debian; as well as comprehensive support for Android 11 through 14.

Communication

High-speed 4G/5G LTE modules, Dual-band Wi-Fi 6, and Gigabit Ethernet.

Sampling
10-15 Working Days
Standard
SUS316L / IP69K
Certifications
CE / FCC / UKCA
Response
8H Expert Team
verified

01 / Warranty Policy

Industry-leading protection for your investment.

Complete System

3 Years Full Warranty for the complete machine assembly.

LCD Module

1 Year Warranty for the original LCD assembly.

Extended Support

Optional extended warranty programs (up to 5 years) available upon request.

support_agent

02 / Field Support

Expert guidance throughout the product lifecycle.

Remote Assistance

24/7 technical support and configuration guidance via video link or remote access.

On-site Services

Local on-site installation and maintenance available for large-scale deployments.

schedule

03 / Production Timeline

Scalable manufacturing for urgent project schedules.

Sample Prototyping

Verification and custom prototype delivery within 10 Working Days.

Bulk Production

Standard bulk order fulfillment in 15 - 25 Working Days.

public

04 / Global Distribution

Reliable logistics via air, sea, or rail.

Express & Air

Door-to-door global delivery in 5 - 7 Working Days (DHL, FedEx, UPS).

Ocean & Rail

Cost-optimized bulk shipping in 30 - 45 Days for global major ports.
