58.5 inch ultra wide stretched LCD digital signage
OEM / ODM Manufacturer
Factory Direct
Order & Lead Time
Need 50+ units? for framework agreements.
Global Shipping Options
Samples ship in ~10 working days; Bulk orders in 15-25 working days.
- Express: DHL/FedEx door-to-door delivery (5-7 days)
- Sea Freight: Cost-optimized bulk shipping (30-45 days)
- Rush Orders: Available upon request for urgent projects
1-3 Year Standard Warranty
3 years for Display Units and 1 year for LCD modules. Extendable to 5 years. Includes 24/7 support, remote troubleshooting, and long-term spare parts availability.
All products are manufactured in our ISO 9001-certified facility.
CE, FCC, RoHS Certified
The RS58.5NET-NE7 is a 58.5 inch ultra wide stretched color TFT-LCD display with special aspect ratio 16:4.5 and wide resolution 3840*1080, it is RisingLCD stretched bar LCD display series product which designed for high brightness 700nits with power efficiency LED backlight. It provides LCD panel with specific aspect ratios and high brightness for digital signage, public transportation, exhibition hall, department store, and vending machine.
· 58.5" stretched LCD
· Stretched display (aspect ratio of 16:4.5)
· Brightness of 700 nits
· Active area: 1428.48(H)*401.76(V)
· Dimension: 1444.08(H)×420.36V)×27.58/57.2(D) mm
· Resolutions: 3840*1080
· Contrast ratio: 1200:1
· Wide viewing angle of 178° (H), 178° (V)
· Low power consumption
· MTBF: 50,000 hours
RisingLCD can offer indoor and outdoor LCD display, ultra wide stretched LCD bar, regular 16:9 digital signage, square LCD screen, round high brightness LCD monitor. size from 10.1 inch to 110 inch, and customized brightness from 500 nits to 5500 nits.
| Screen Diagonal | 58.5 inch |
| Model No | RS58.5NET-NE7 |
| Active Area | 1428.48(W)×401.76(H) mm |
| Pixels | 3840(RGB)×1080, 41PPI68 |
| Physical Size | 1444.08(H)×420.36V)×27.58/57.2(D) mm |
| Pixel Arrangement | R.G.B. Vertical Stripe |
| Display Mode | a-Si TFT-LCD, LCM |
| White Luminance ( Center ) | 700 cd/m2 (Typ.) [cd/m2 ] |
| Contrast Ratio | 1200:1 (Typ.) |
| Optical Response Time | 8 (Typ.)(G to G) |
| Back light | down edge side, 2-led light bar |
| OS | Android 8.0 |
| Viewing Angle | 89/89/89/89 (Typ.)(CR≥10) |
| Support Color | 16.7M, 72% NTSC |
| Surface Treatment | Antiglare (Haze 28%) |
| RoHS Compliance | RoHS Compliance |
| Operating Temperature | -20 ~ 70 °C |
| Storage Temperature | -30 ~ 80 °C |
| Weight [g] | 11.8Kgs |
| VESA Mounting | 300*400mm |
01 / Chassis & Materials
Structural integrity for extreme environments.
| Enclosure Grade | Medical and Food grade SUS316L Stainless Steel, AL5052 Aluminum, or SECC Galvanized Steel. |
| Protection Rating | Certified IP65 / IP69K waterproof sealing. Mechanical impact protection rated at IK10. |
| Surface Finish | Industrial powder coating (RAL spectrum), sandblasting, and anti-acid marine painting. |
| Format Architecture | Chassis-mount, Open-frame, Panel-mount, and VESA-integrated configurations. |
03 / Interface & I/O
Industrial signal and power regulation.
| Connectors | Support for M12 Aviation Circular Connectors, DB9/RS232, and waterproof RJ45/USB. |
| Power Regulation | Wide voltage DC 9V - 36V input with integrated surge and polarity protection. |
| Sensor Suite | Integrated ambient light sensors, thermal probes, and custom GPIO control protocols. |
02 / Optical & Display
Visibility optimization for extreme ambient lighting.
| Luminance Output | Scalable 1500 - 5000 Nits with integrated Hi-Tni (110°C) anti-blackening technology. |
| Optical Bonding | Full Vacuum Optical Bonding (OCR) — eliminates air gaps, fogging, and maximizes contrast ratio. |
| Advanced Coating | Integrated AR (Anti-Reflective), AG (Anti-Glare), and AF (Anti-Fingerprint) nano-films. |
04 / Embedded & Data
Software architecture and data sync.
| Operating Systems | Full compatibility with Windows 7, 10/11 IoT; Linux support covering the last 3 generations (Ubuntu 20.04, 22.04, 24.04 LTS) and Debian; as well as comprehensive support for Android 11 through 14. |
| Communication | High-speed 4G/5G LTE modules, Dual-band Wi-Fi 6, and Gigabit Ethernet. |
