The RisingStar 21.5-inch open frame touch LCD display is designed for professional applications that demand excellent outdoor visibility. Featuring 1000 nits high brightness, full HD resolution, and a durable open frame design, this sunlight readable display ensures crystal-clear performance even under direct sunlight. It is an ideal solution for self-service kiosks, EV charging stations, retail signage, fuel dispensers, and industrial control panels.
| Item | Specification |
|---|---|
| Panel Size | 21.5 inch |
| Panel Type | a-Si TFT-LCD, LCD Module |
| Resolution | 1920 (RGB) × 1080, FHD, 102 PPI |
| Pixel Arrangement | RGB Vertical Stripe |
| Active Display Area | 476.064 (W) × 267.786 (H) mm |
| Viewing Area | 479.8 (W) × 271.3 (H) mm |
| Surface Treatment | Matte (Haze 25%), Hard Coating (3H) |
| Brightness | 1000 to 5000 nits |
| Contrast Ratio | 1000:1 (Typ.) [Transmissive] |
| Optical Mode | IPS, Normally Black, Transmissive |
| Viewing Angle (CR≥10) | 89/89/89/89 (Left/Right/Up/Down) |
| Response Time | 14 ms (Typ., G-to-G) |
| Color Depth | 16.7M Colors, 72% NTSC |
| Backlight Type | 17S2P WLED, 30,000 hrs, Driverless |
| Weight | 1.69 / 1.77 kg (Typ./Max.) |
| Applications | Computer Monitor, Industrial, Healthcare |
| Refresh Rate | 75 Hz 120 Hz (60 Hz input) with MEMC 120 Hz + 120 Hz (Panel + Backlight) 240 Hz (60 Hz input) with MEMC |
| Touch Function | No Touch |
| Signal Interface | LVDS (2 ch, 8-bit), 30 Pins |
| Supply Voltage | 5.0 V (Typ.) |
| Storage Temperature | -20 ~ 70 °C |
| Operating Temperature | -20 ~ 50 °C |
Sunlight Readable: 1000 nits brightness with anti-glare treatment for clear outdoor viewing.
Rugged Open Frame Design: Industrial-grade aluminum housing, easy integration into kiosks and terminals.
Touch Functionality: Responsive touch interface with high durability.
Energy Efficient: Low power consumption, low heat output for 24/7 operation.
Wide Temperature Range: Reliable performance in harsh outdoor environments.
Long Lifespan: Over 50,000 hours of operation, tested under extreme conditions.
With more than 15 years of expertise in industrial LCD technology, RisingStar delivers display solutions trusted by global partners in transportation, retail, energy, and smart city projects. Our engineering team performs strict testing for brightness, contrast, and temperature durability, ensuring every display meets international quality standards.
EV Charging Stations: Ensures drivers can easily read instructions even under direct sunlight.
Retail & Outdoor Signage: Boosts brand visibility with vivid and clear digital messages.
Public Information Displays: Deployed in railway and bus terminals for reliable passenger information delivery.
“We integrated RisingStar’s sunlight readable displays into our outdoor kiosks. The clarity under bright sunlight exceeded expectations, and the durability has been outstanding.”
— Project Manager, European EV Infrastructure Company
ISO 9001 Certified Manufacturing
CE & RoHS Compliant
IP-rated protection for outdoor integration
This product description was reviewed by RisingStar’s senior display engineer, with over a decade of experience in LCD backlight design and outdoor digital signage integration.
RisingStar is committed to providing transparent service and long-term support:
Clear warranty and return policy
Dedicated technical support team
Global distribution and fast delivery
📞 Contact Us: [https://www.risinglcd.com/contact.html] | ✉️ ai@risinglcd.com
1000 nit sunlight readable open frame LCD display with a 21.5 inch touch screen, 1920*1080 full HD, wide viewing angle 89/89/89/89 LCD panel, HDMI video input and open frame metal enclosure. Option for Resistive/capacitive/PCAP type touch screen.
Metal Open frame construction
Industrial 2k (1920 x 1080) full HD LED backlight industrial monitor
Sunlight readable 1000-nit high brightness LCD monitor
VGA + DVI-D video input
External 100/240 auto-sensing AC power adapter
High performance mainboard, 7x24 continuous operation.
Wide temperature range: operating: -10 to 70°C, storage: -20 to 80°C.
Support wall mounting, embedded mounting, desk stand mounting etc.
Option for HDMI, DP, Audio, or 3G/HD/SD-SDI input
Option for Resistive, Capacitive, or PCAP type touch screen
Option for 12V / 24V / 48V DC power input
| Item | Specification |
|---|---|
| Panel Size | 21.5 inch |
| Panel Type | a-Si TFT-LCD, LCD Module |
| Resolution | 1920 (RGB) × 1080, FHD, 102 PPI |
| Pixel Arrangement | RGB Vertical Stripe |
| Active Display Area | 476.064 (W) × 267.786 (H) mm |
| Viewing Area | 479.8 (W) × 271.3 (H) mm |
| Surface Treatment | Matte (Haze 25%), Hard Coating (3H) |
| Brightness | 1000 to 5000 nits |
| Contrast Ratio | 1000:1 (Typ.) [Transmissive] |
| Optical Mode | IPS, Normally Black, Transmissive |
| Viewing Angle (CR≥10) | 89/89/89/89 (Left/Right/Up/Down) |
| Response Time | 14 ms (Typ., G-to-G) |
| Color Depth | 16.7M Colors, 72% NTSC |
| Backlight Type | 17S2P WLED, 30,000 hrs, Driverless |
| Weight | 1.69 / 1.77 kg (Typ./Max.) |
| Applications | Computer Monitor, Industrial, Healthcare |
| Refresh Rate | 75 Hz 120 Hz (60 Hz input) with MEMC 120 Hz + 120 Hz (Panel + Backlight) 240 Hz (60 Hz input) with MEMC |
| Touch Function | No Touch |
| Signal Interface | LVDS (2 ch, 8-bit), 30 Pins |
| Supply Voltage | 5.0 V (Typ.) |
| Storage Temperature | -20 ~ 70 °C |
| Operating Temperature | -20 ~ 50 °C |
Ask a quote for the latest price and one of our team members will respond as soon as possible.
