32 inch 4K high brightness TFT LCD panel

32 inch 4K high brightness TFT LCD panel

BrandRisingstar
Model nameRS315DJJ-NE10
Screen size31.5"
Screen typeOutdoor LCD Panel
Resolution3840(RGB)×2160
Brightness (cd/m²)1000
Overview Specifications Customized Services Support & Shipping

RS315DJJ-NE10 high brightness TFT LCD display has a 3840* 2160 ultra high resolution, wide view 178×178 angle, it can easily captivates customers with its vivid image quality and quiet operation, it can helps business enhance thier brand image while enriching the customer's shopping experinece. The customized brightness are option: 500nits, 800nits, 1000nits, and 1500nits.

RS315DJJ-NE10 high brightness TFT LCD Main Features:

Resolution: 3840x2160 (UHD) 59PPI,

High Brightness: 1000 nits with auto-light sensor.

wide viewing angles: 178° veiw angle
7*24 hours working uninterrupted

support Landscape & portrait Installation way

1000nits High Brightness,

Image’s high brightness is a highly desired feature in a strong sunlight situation, thanks to this attribute, our displayed contents is fully readable, displays with high brightness may be successfully used e.g in expositions, buses station, digital signage or other outdoor application.

4K Ultra HD resolution.

The 4K Ultra HD picture quality ensures great colour and rich details in all possible broadcasting surroundings, ranging from retail stores, to restaurants and office buildings.

Landscape & portrait

Both landscape and portrait orientations are possible, providing you with endless creative and functional possibilities to fulfill your commercial or informative goals

RS315DJJ-NE10 31.5 inch high brightness display 31.5 inch sunlight readable LCD High brightness display Sunlight readable display Outdoor waterproof display
Screen Diagonal31.5  inch
panel noRS315DJJ-NE10
Brand Risingstar
Model NoRS315DJJ-NE10
Active Area698.4(H)X 392.85(V)
Resolution3840(RGB)×2160, UHD, 139PPI
Physical Size731.1(W)×425.7(H)×32.9(D) mm
Pixel ArrangementR.G.B. Vertical Stripe
Display Modea-Si TFT-LCD, LCM
Contrast Ratio :3000:1
White Luminance ( Center )1000 cd/m2 (Typ.)  [cd/m2 ]
Optical Response Time9.5 (Typ.)(G to G) ms
Nominal Input Voltage12 V (Typ.)
Frame Rate60Hz
Viewing Angle89/89/89/89 (Typ.)(CR≥10)
Weight [g]6.6kgs
Interface Type51 pins   V-by-One 8 lane ,
Support Color1.07B , 79% NTSC
Surface TreatmentMatte (Haze 25%) , Hard coating (3H)
RoHS ComplianceRoHS Compliance
Operating Temperature-20 ~ 70 °C
Storage Temperature-30 ~ 80 °C
inventory_2

01 / Chassis & Materials

Structural integrity for extreme environments.

Enclosure Grade

Medical and Food grade SUS316L Stainless Steel, AL5052 Aluminum, or SECC Galvanized Steel.

Protection Rating

Certified IP65 / IP69K waterproof sealing. Mechanical impact protection rated at IK10.

Surface Finish

Industrial powder coating (RAL spectrum), sandblasting, and anti-acid marine painting.

Format Architecture

Chassis-mount, Open-frame, Panel-mount, and VESA-integrated configurations.

blur_on

02 / Optical & Display

Visibility optimization for extreme ambient lighting.

Luminance Output

Scalable 1500 - 5000 Nits with integrated Hi-Tni (110掳C) anti-blackening technology.

Optical Bonding

Full Vacuum Optical Bonding (OCR) - eliminates air gaps, fogging, and maximizes contrast ratio.

Advanced Coating

Integrated AR (Anti-Reflective), AG (Anti-Glare), and AF (Anti-Fingerprint) nano-films.

settings_input_component

03 / Interface & I/O

Industrial signal and power regulation.

Connectors

Support for M12 Aviation Circular Connectors, DB9/RS232, and waterproof RJ45/USB.

Power Regulation

Wide voltage DC 9V - 36V input with integrated surge and polarity protection.

Sensor Suite

Integrated ambient light sensors, thermal probes, and custom GPIO control protocols.

dns

04 / Embedded & Data

Software architecture and data sync.

Operating Systems

Full compatibility with Windows 7, 10/11 IoT; Linux support covering the last 3 generations (Ubuntu 20.04, 22.04, 24.04 LTS) and Debian; as well as comprehensive support for Android 11 through 14.

Communication

High-speed 4G/5G LTE modules, Dual-band Wi-Fi 6, and Gigabit Ethernet.

Sampling
10-15 Working Days
Standard
SUS316L / IP69K
Certifications
CE / FCC / UKCA
Response
8H Expert Team
verified

01 / Warranty Policy

Industry-leading protection for your investment.

Complete System

3 Years Full Warranty for the complete machine assembly.

LCD Module

1 Year Warranty for the original LCD assembly.

Extended Support

Optional extended warranty programs (up to 5 years) available upon request.

support_agent

02 / Field Support

Expert guidance throughout the product lifecycle.

Remote Assistance

24/7 technical support and configuration guidance via video link or remote access.

On-site Services

Local on-site installation and maintenance available for large-scale deployments.

schedule

03 / Production Timeline

Scalable manufacturing for urgent project schedules.

Sample Prototyping

Verification and custom prototype delivery within 10 Working Days.

Bulk Production

Standard bulk order fulfillment in 15 - 25 Working Days.

public

04 / Global Distribution

Reliable logistics via air, sea, or rail.

Express & Air

Door-to-door global delivery in 5 - 7 Working Days (DHL, FedEx, UPS).

Ocean & Rail

Cost-optimized bulk shipping in 30 - 45 Days for global major ports.
