| Parameter | Specification |
|---|---|
| Panel Size | 43" |
| Panel Type | a-Si TFT-LCD, LCD Module |
| Resolution | 1920 (RGB) × 1080, FHD, 51 PPI |
| Pixel Arrangement | RGB Vertical Stripe |
| Active Area | 940.896(W) × 529.254(H) mm |
| Viewable Area | - |
| Surface Treatment | Anti-glare (Haze 1%), Hard Coating (3H) |
| Brightness | 500 ~ 5000 nits |
| Contrast Ratio | 1200:1 (Typ.) |
| Viewing Angle | 89° / 89° / 89° / 89° (Typ., CR≥10) L/R/U/D |
| Operating Mode | ADS, Normally Black, Transmissive |
| Panel Series | IPS Hard Panels: AAS, ADS, AHVA, FFS, HFS, HIS, IPS, New Mode2, PLS, SFT, Vistarich VA Soft Panels: ASV, FSA, HVA, MVA, PVA, SVA, UV²A, VA |
| Viewing Direction | Full Angle |
| Response Time | 8 ms (Typ., G to G) |
| Display Colors | 16.7M, 72% NTSC |
| Backlight Type | WLED, 30,000 hours, with LED driver |
| Refresh Rate | 60Hz 120Hz (60Hz input, built-in MEMC) 120Hz+120Hz: 120Hz panel + 120Hz backlight 240Hz (60Hz input) |
| Panel Weight | 8.36 kg (Typ.) |
| Applications | Digital Signage, Advertising Displays, Public Information Screens |
| Signal Interface | LVDS (2 ch, 8-bit), 51 pins |
| Driving Voltage | 12.0V (Typ.) |
| Operating Environment | Operating: 0 ~ 50 °C; Storage: -20 ~ 60 °C |
Application Note:
This 43" high-brightness, wide-viewing-angle FHD panel is ideal for digital signage, storefront advertising, interactive kiosks, and public information displays, providing clear, vivid images even in bright ambient light.
| Parameter | Specification |
|---|---|
| Panel Size | 43" |
| Panel Type | a-Si TFT-LCD, LCD Module |
| Resolution | 1920 (RGB) × 1080, FHD, 51 PPI |
| Pixel Arrangement | RGB Vertical Stripe |
| Active Area | 940.896(W) × 529.254(H) mm |
| Viewable Area | - |
| Surface Treatment | Anti-glare (Haze 1%), Hard Coating (3H) |
| Brightness | 500 ~ 5000 nits |
| Contrast Ratio | 1200:1 (Typ.) |
| Viewing Angle | 89° / 89° / 89° / 89° (Typ., CR≥10) L/R/U/D |
| Operating Mode | ADS, Normally Black, Transmissive |
| Panel Series | IPS Hard Panels: AAS, ADS, AHVA, FFS, HFS, HIS, IPS, New Mode2, PLS, SFT, Vistarich VA Soft Panels: ASV, FSA, HVA, MVA, PVA, SVA, UV²A, VA |
| Viewing Direction | Full Angle |
| Response Time | 8 ms (Typ., G to G) |
| Display Colors | 16.7M, 72% NTSC |
| Backlight Type | WLED, 30,000 hours, with LED driver |
| Refresh Rate | 60Hz 120Hz (60Hz input, built-in MEMC) 120Hz+120Hz: 120Hz panel + 120Hz backlight 240Hz (60Hz input) |
| Panel Weight | 8.36 kg (Typ.) |
| Applications | Digital Signage, Advertising Displays, Public Information Screens |
| Signal Interface | LVDS (2 ch, 8-bit), 51 pins |
| Driving Voltage | 12.0V (Typ.) |
| Operating Environment | Operating: 0 ~ 50 °C; Storage: -20 ~ 60 °C |
Ask a quote for the latest price and one of our team members will respond as soon as possible.
