The TFT passenger information display uses an industrial LCD panel with high reliability and high definition to provide passengers with a better reading experience. It is suitable for trains, subways, airport information displays and various commercial displays.
RS485IVN-GE08 is RisingLCD 48.5 inch high brightness panel for passenger information, 1920*360 FHD resolution, 800 nits high brightness, 4000:1 contrast ratio, matte surface treatment, LVDS interface. Due to the ultra wide aspect ratio, these displays are ideal to used to exhibit stop names, transport timetables, traffic message, announcements and other important notices as the passenger information display.
48.5 inch stretch high brightness passenger information display main features:
1. 1920x360 Resolution,
2. 800 nits high brightness brightness
3. 4000:1 contrast ratio
4. Built-in Auto light sensor, lower power consumption
5. High quality panel with 89/89/89/89 viewing angle.
6. LVDs interface
Product technology
1. Our high brightness passenger information displays are equipped with original industrial-grade open cell from SAMSUNG, LG, AUO, LNNOLUX, BOE, TCL CSOT, etc., our own special designed advanced LED backlight will make the brightness more uniform, delicate colors, and vivid images.
2. Adopt aluminum alloy or sheet metal rim shell, surface anodization treatment or powder spraying treatment, cold-rolled steel plate back shell, active heat dissipation
Ultra wide High brightness display
This stretch passenger information display with ultra wide screen, are best options among passenger information display, 48.5 inch wide size ensures that the screen remains visible easily, and making it easy for passengers to read important information and messages in the bus station, railway station and airport.
48.5 inch stretch passenger information LCD panel, provides real-time information to the passengers to decrease perceived waiting times, improving customers satisfaction.
48.5 inch high brightness Passenger information panel is flexible enough to display a variety of information including train routes, real-time information, offer the passenger a full-service digital signage platform. RisingLCD can produce and supply different sizes passenger information screen to meet you different request, such as concourse display, metro platform display, train information display.
Screen Diagonal | 48.5 inch |
Brand | Risingstar |
Model No | RS485IVN-GE08 |
Active Area | 1209.6(H)*226.8(V) |
Resolution | 1920*360 |
Physical Size | 1221(H)*252.2(V)*33.5(D) |
Pixel Arrangement | R.G.B. Vertical Stripe |
Display Mode | a-Si TFT-LCD, LCM |
Contrast Ratio : | 4000:1 |
White Luminance ( Center ) | 800 cd/m2 (Typ.) [cd/m2 ] |
Optical Response Time | 8 (Typ.)(G to G) ms |
Nominal Input Voltage | 12.0V (Typ.) |
Frame Rate | 60Hz |
Viewing Angle | 89/89/89/89 (Typ.)(CR≥10) |
Weight [kg] | 4.47kgs |
Interface Type | LVDS (2 ch, 8-bit) , 51 pins |
Support Color | 16.7M/1.07B |
Surface Treatment | Matte (Haze 3%) |
RoHS Compliance | RoHS Compliance |
Temperature Range | 0 ~50 °C |
Storage (Non-Operating) | -20 ~ 60 °C |
Ask a quote for the latest price and one of our team members will respond as soon as possible.
