46inch window digital signage display with 4000nits high brightness

46inch window digital signage display with 4000nits high brightness

Panel BrandLG display
Panel Model No.LD460DUY-ZQA1
Screen size46"
Resolution1920*1080,
Brightness (cd/m²)4000

RS460ENT-N40 is high brightness digital signage display that take use of LG commercial grade panel, it is designed for shopping mail, show window, fashion stores.

46inch window digital signage display Description

**Material: Aluminum frame +LCD panel

**Function: advertising display

**Package:High Quality wooden carton

**Display, Full view angle screen, 1920*1080 FHD, LCD backlight, View angle: 89/89(H),89/89(V); Contrast ratio:1000; Brightness: 4000cdm2; Ratio: 16:9

**Support: landscape and portrain

**Installation Ways: Hang to the celling, mounted to wall, floor standing.

46inch window digital signage display Main features

1. Outstanding visibility high brightness

RisingLCD RS460ENT-N40 was designed with a storefront window display in mind, with a great brightness of 4000nits, it can projects clear, bright images that attract and engage audiences, increasing the probability of an in-store visit and consumption.

2.Wide viewing angles

Thanks to using a matrix with IPS/MVA technology, our high brightness display is readable from any angle. There is no gray scale inversion effect which is a normal feature of popular TN matrixes. A decrease in contrast when increasing the viewing angle is also significantly lower. Superior image quality and color depth at 178 degree ultra-wide portrait orientations. It does not produce image distortion and minimizes color shift when viewed from different angles, it provides clear images and instantly optimizes screen color and brightness.


3. Smart brightness control

The built-in auto-brightness sensor adjusts backlight brightness according to the surrounding brightness to save power energy and protect your eyes.

4.Blackening Defect Free

Most residential and commercial LCD panel exposed to directly sunlight will blacken or result in isotropic failure. RisingLCD high brightness window facing displays are equipped with a high-temperature LCD panel capable of withstanding temperatures up to 110˚C (230°F) without blackening – crucial for direct sunlight applications.

5. Protective glass

Our high brightness window facing is covered with he tempered and laminated front glass that ensures optimum protection from outdoor extremities, resulting in minimal to no damage form extrenal impacts.

OEM and ODM are welcomed!

RisingLCD is a professional highlight LCD manufacturer from China, specializes in manufacturing and distributing all types of LCD module, LCD monitors, open frame monitor, outdoor and indoor digital signage and goods are exported all of the world, could customize the products based on the customer needs with a competitive price, RisingLCD is your best choice!

LD460DUY-ZQA1 46 inch high brightness display 46 inch sunlight readable LCD High brightness display Sunlight readable display Outdoor waterproof display
Factory   Model No: RS460ENT-N40
Panel Brand LG  Display
Panel No.: LD460DUY-ZQA1
Screen Size46"
Panel TechnologyIPS, M+ (WRGB)
Active Area(mm)1018.08*572.67(H×V)mm
Panel Type. a-Si TFT-LCD, CELL
Aspect Ratio16:09
Native Resolution1920*1080(FHD) 102PPI
Refresh Rate60Hz
Brightness4000nit (Typ, w/ Glass)
Contrast Ratio1000:1 (Typ)
Dynamic CR500,000:1
Color gamut16.7M/1.07B, 68% NTSC
Viewing Angle (H x V)178 x 178
Support Color: 16.7M/1.07B,
Response Time8 (Typ.) (G+G)ms
Display ModeIPS, normally Black, Transmissive
Surface Treatment (Haze)Antiglare(Haze 3%), Hard coating (2H)
Transmissivity6.30% (Typ.)(with Polarizer)
Life time50,000 Hrs (Typ)
Operation Hours (Hours/Day)24/7
Operating Temperature:-20 ~ 70 °C
Storage Temperature:-30 ~ 80 °C
Portrait / LandscapeYes / Yes
Jack interface input HDMI (2), , RS232C IN (4pin phone jack), RJ45(LAN), IR IN,   USB2.0 Type A (1)
Jack interface output DP Out (Input DP/HDMI), Externel Speaker Out (L/R, 10W+10W),   RS232C OUT
Net work supportLAN/WLAN/3G/4G/5G   network.
