49 inch ultra thinner high brightness window facing display
OEM / ODM Manufacturer
Factory Direct
Order & Lead Time
Need 50+ units? for framework agreements.
Global Shipping Options
Samples ship in ~10 working days; Bulk orders in 15-25 working days.
- Express: DHL/FedEx door-to-door delivery (5-7 days)
- Sea Freight: Cost-optimized bulk shipping (30-45 days)
- Rush Orders: Available upon request for urgent projects
1-3 Year Standard Warranty
3 years for Display Units and 1 year for LCD modules. Extendable to 5 years. Includes 24/7 support, remote troubleshooting, and long-term spare parts availability.
All products are manufactured in our ISO 9001-certified facility.
CE, FCC, RoHS Certified
Global Industry Leader in High Brightness Window Facing Display
49 inch ultra thinner high brightness window facing display – Engineered for Sunlight Readability & 24/7 Durability. Perfect for storefronts, outdoor signage, and high-traffic areas. Features IP65 weatherproofing, anti-glare coating, and 30% energy savings. Custom brackets, instant quotes. Shop direct from factory – ISO-certified, 3-year warranty.
Features an ultra-thin design paired with an anti-glare high-brightness panel and 170° wide viewing angle, ensuring vivid and sharp visuals even under direct sunlight. With IP65-rated protection, low power consumption, and long-lasting durability, it is ideal for commercial storefronts, outdoor advertising, and similar environments.
Professional customized solutions for size and installation, supporting flexible customization from 21.5 to 55 inches.
Size (inch) | 21.5 | 32 | 43 | 49 | 55 |
Model number | RS215MNX01D01 | RS320HNX02D05 | RS430MNX03D01 | RS490MNX01D01 | RS550MNX01D01 |
Brightness (cd/m2) | 1000 | 3000 | 2500 | 2000 | 3000 |
Resolution (pixels) | 1920*1080 | 1920*1080 | 1920*1080 | 1920*1080 /3840*2160 | 1920*1080 /3840*2160 |
Power (Watt) | 80 | TBD | |||
Opreating temperature | -20 ~ 70 °C | -20 ~ 70 °C | -20 ~ 70 °C | -20 ~ 70 °C | -20 ~ 70 °C |
High adaptability electronic
Risingstar has customers from all over the world, EU, US, Asia...using the right plug and adapt different voltage is the basic issue we should figure out for our customers, you do not need worry about this; the possibly OS for the display, we can offer both PC and Android to make you using easier; also the interfaces, HDMI/USB/VGA/DVI/DP/Type-C/RJ45 by your choice, our enegineer will help you found the most suitable motherboard.
IK10 tempered glass with optical bonding provides the strongest protection
We hold globally recognized certifications (ISO 9001, CE, RoHS, TÜV, UL, IP65/67) to ensure seamless customs clearance and compliance for your projects.
Provide customized LCD screen sizes for various fuel dispensers
10.1 inches to 110 inches, please contact info@risinglcd.com
Model Name | RS490MNX02D01-BK |
Screen Size | 49" |
Display Area (mm) | 1073.78(W)×604(H) mm |
Brightness | 2500 cd/m2 |
Resolution | 1920x1080 |
Aspect Ratio | 16 : 9 |
Contrast Ratio | 1100 : 1 |
Response Time (Typical) | 6(Typ.)(Tr/Td) (ms) |
Viewing Angle | 89/89/89/89 (Min.)(CR≥10) |
Display Colors | 16.7M |
OS | N/A |
Glass | N/A |
Touch Type | N/A |
Input Power | AC100-240V |
Power Consumption | TBD |
Radiator System | N/A |
Input Interface | PC AUDIO IN*1 EARPHONE OUT*1 DVI*1 VGA*1 HDMI *1 AC IN*1 |
Dimensions (mm) | 1098.8*629*50mm |
Mounting | 400x400mm 4-M8,MAX_DEPTH=10mm |
Weight (Net) | TBD |
IP（Ingress Protection） | N/A |
Operating Temperature | -20 ~ 70 °C |
Storage Temperature | -30 ~ 80 °C |
01 / Chassis & Materials
Structural integrity for extreme environments.
| Enclosure Grade | Medical and Food grade SUS316L Stainless Steel, AL5052 Aluminum, or SECC Galvanized Steel. |
| Protection Rating | Certified IP65 / IP69K waterproof sealing. Mechanical impact protection rated at IK10. |
| Surface Finish | Industrial powder coating (RAL spectrum), sandblasting, and anti-acid marine painting. |
| Format Architecture | Chassis-mount, Open-frame, Panel-mount, and VESA-integrated configurations. |
03 / Interface & I/O
Industrial signal and power regulation.
| Connectors | Support for M12 Aviation Circular Connectors, DB9/RS232, and waterproof RJ45/USB. |
| Power Regulation | Wide voltage DC 9V - 36V input with integrated surge and polarity protection. |
| Sensor Suite | Integrated ambient light sensors, thermal probes, and custom GPIO control protocols. |
02 / Optical & Display
Visibility optimization for extreme ambient lighting.
| Luminance Output | Scalable 1500 - 5000 Nits with integrated Hi-Tni (110°C) anti-blackening technology. |
| Optical Bonding | Full Vacuum Optical Bonding (OCR) — eliminates air gaps, fogging, and maximizes contrast ratio. |
| Advanced Coating | Integrated AR (Anti-Reflective), AG (Anti-Glare), and AF (Anti-Fingerprint) nano-films. |
04 / Embedded & Data
Software architecture and data sync.
| Operating Systems | Full compatibility with Windows 7, 10/11 IoT; Linux support covering the last 3 generations (Ubuntu 20.04, 22.04, 24.04 LTS) and Debian; as well as comprehensive support for Android 11 through 14. |
| Communication | High-speed 4G/5G LTE modules, Dual-band Wi-Fi 6, and Gigabit Ethernet. |
