65" Ultra High Brightness TFT/IPS LCD Screen
OEM / ODM Manufacturer
Factory Direct
Order & Lead Time
Need 50+ units? for framework agreements.
Global Shipping Options
Samples ship in ~10 working days; Bulk orders in 15-25 working days.
- Express: DHL/FedEx door-to-door delivery (5-7 days)
- Sea Freight: Cost-optimized bulk shipping (30-45 days)
- Rush Orders: Available upon request for urgent projects
1-3 Year Standard Warranty
3 years for Display Units and 1 year for LCD modules. Extendable to 5 years. Includes 24/7 support, remote troubleshooting, and long-term spare parts availability.
All products are manufactured in our ISO 9001-certified facility.
CE, FCC, RoHS Certified
65" High Brightness LCD Display – All Models (RisingStar)
Normal Series (D Series)
| Model No. | Brightness (nits) | Resolution |
|---|---|---|
| RS650ENT-ND20 | 2000 | 3840 × 2160 |
| RS650ENT-ND25 | 2500 | 3840 × 2160 |
| RS650ENT-ND30 | 3000 | 3840 × 2160 |
| RS650ENT-ND35 | 3500 | 3840 × 2160 |
| RS650ENT-ND40 | 4000 | 3840 × 2160 |
| RS650ENT-ND45 | 4500 | 3840 × 2160 |
| RS650ENT-ND50 | 5000 | 3840 × 2160 |
65" a-Si TFT-LCD Panel Specifications (ADS / IPS Hard-Screen Series)
| Feature | Specification |
|---|---|
| Panel Size | 65" |
| Panel Type | a-Si TFT-LCD Module |
| Resolution | 3840 × 2160 (UHD), 68 PPI, RGB Vertical Stripe |
| Active Display Area | 1428.48 × 803.52 mm |
| Viewable Area | - |
| Surface Treatment | Anti-glare (Haze 1%), Hard Coating 3H |
| Brightness | 2000 ~ 5000 nits |
| Contrast Ratio | 1200:1 (Typ.) |
| Viewing Angle | 89° / 89° / 89° / 89° (Left / Right / Up / Down, CR≥10) |
| Viewing Direction | Full-angle |
| Response Time | 8 ms (Typ., G to G) |
| Display Colors | 1.07B, 72% NTSC |
| Backlight Type | 5 strings WLED, 50,000 hours, with LED driver |
| Operating Frequency | 60Hz; Built-in MEMC supports 120Hz (60Hz input) |
| Advanced Frequency Options | 120Hz+120Hz: 120Hz panel + 120Hz backlight 240Hz (60Hz input) |
| Panel Weight | 18.9 kg (Typ.) |
| Signal Interface | V-by-One 8 lane, 51 pins |
| Driving Voltage | 12.0V (Typ.) |
| Operating Environment | Working: -20 ~ 70 °C Storage: -20 ~ 70 °C |
| Operating Mode | ADS, Normally Black, Transmissive |
Supported Panel Series:
IPS Hard Screen: AAS, ADS, AHVA, FFS, HFS, HIS, IPS, New Mode2, PLS, SFT, Vistarich
VA Soft Screen: ASV, FSA, HVA, MVA, PVA, SVA, UV²A, VA
Notes & Applications
Ultra-Bright & Wide Viewing: With up to 5000 nits brightness and 89° full viewing angles, this 65" panel is ideal for high-visibility applications in outdoor or bright indoor environments.
Durable Design: Anti-glare hard coating and long-life WLED backlight ensure low maintenance and extended operational lifespan.
High Performance: ADS technology provides excellent color consistency, fast response, and wide viewing angles. MEMC support ensures smooth motion display for digital signage or video content.
Applications:
Digital signage for retail stores, airports, and transportation hubs
Outdoor advertising screens and window-facing displays
Public information displays (passenger information, wayfinding)
Large-format video walls and interactive kiosks
65" a-Si TFT-LCD Panel Specifications (ADS / IPS Hard-Screen Series)
| Feature | Specification |
|---|---|
| Panel Size | 65" |
| Panel Type | a-Si TFT-LCD Module |
| Resolution | 3840 × 2160 (UHD), 68 PPI, RGB Vertical Stripe |
| Active Display Area | 1428.48 × 803.52 mm |
| Viewable Area | - |
| Surface Treatment | Anti-glare (Haze 1%), Hard Coating 3H |
| Brightness | 2000 ~ 5000 nits |
| Contrast Ratio | 1200:1 (Typ.) |
| Viewing Angle | 89° / 89° / 89° / 89° (Left / Right / Up / Down, CR≥10) |
| Viewing Direction | Full-angle |
| Response Time | 8 ms (Typ., G to G) |
| Display Colors | 1.07B, 72% NTSC |
| Backlight Type | 5 strings WLED, 50,000 hours, with LED driver |
| Operating Frequency | 60Hz; Built-in MEMC supports 120Hz (60Hz input) |
| Advanced Frequency Options | 120Hz+120Hz: 120Hz panel + 120Hz backlight 240Hz (60Hz input) |
| Panel Weight | 18.9 kg (Typ.) |
| Signal Interface | V-by-One 8 lane, 51 pins |
| Driving Voltage | 12.0V (Typ.) |
| Operating Environment | Working: -20 ~ 70 °CC Storage: -20 ~ 70 °CC |
| Operating Mode | ADS, Normally Black, Transmissive |
01 / Chassis & Materials
Structural integrity for extreme environments.
| Enclosure Grade | Medical and Food grade SUS316L Stainless Steel, AL5052 Aluminum, or SECC Galvanized Steel. |
| Protection Rating | Certified IP65 / IP69K waterproof sealing. Mechanical impact protection rated at IK10. |
| Surface Finish | Industrial powder coating (RAL spectrum), sandblasting, and anti-acid marine painting. |
| Format Architecture | Chassis-mount, Open-frame, Panel-mount, and VESA-integrated configurations. |
03 / Interface & I/O
Industrial signal and power regulation.
| Connectors | Support for M12 Aviation Circular Connectors, DB9/RS232, and waterproof RJ45/USB. |
| Power Regulation | Wide voltage DC 9V - 36V input with integrated surge and polarity protection. |
| Sensor Suite | Integrated ambient light sensors, thermal probes, and custom GPIO control protocols. |
02 / Optical & Display
Visibility optimization for extreme ambient lighting.
| Luminance Output | Scalable 1500 - 5000 Nits with integrated Hi-Tni (110°C) anti-blackening technology. |
| Optical Bonding | Full Vacuum Optical Bonding (OCR) — eliminates air gaps, fogging, and maximizes contrast ratio. |
| Advanced Coating | Integrated AR (Anti-Reflective), AG (Anti-Glare), and AF (Anti-Fingerprint) nano-films. |
04 / Embedded & Data
Software architecture and data sync.
| Operating Systems | Full compatibility with Windows 7, 10/11 IoT; Linux support covering the last 3 generations (Ubuntu 20.04, 22.04, 24.04 LTS) and Debian; as well as comprehensive support for Android 11 through 14. |
| Communication | High-speed 4G/5G LTE modules, Dual-band Wi-Fi 6, and Gigabit Ethernet. |
