32inch QLED 4K high brightness digital signage display

32inch QLED 4K high brightness digital signage display

RisingStar® 32 inch M320QAN02.6 sunlight readable display. 3000 nits high brightness, 3840(RGB)×2160 resolution, Hi-Tni solar-resilient for 24/7 outdoor use.

OEM / ODM Manufacturer

Factory Direct

Order & Lead Time

Sample Order 1 Unit MOQ
Bulk Order 10+ Units Tiered Discounts

Need 50+ units? for framework agreements.

Global Shipping Options

Samples ship in ~10 working days; Bulk orders in 15-25 working days.

  • Express: DHL/FedEx door-to-door delivery (5-7 days)
  • Sea Freight: Cost-optimized bulk shipping (30-45 days)
  • Rush Orders: Available upon request for urgent projects

Flexible Warranty Options (1 to 5 Years)

As an OEM/ODM manufacturer, we offer highly customizable warranty plans. Choose the standard coverage for cost-sensitive projects, or opt for our premium 3-5 year extended warranty for mission-critical digital signage deployments.

All products are manufactured in our ISO 9001-certified facility.
CE, FCC, RoHS Certified

Get Started

Full Specifications

Item No:RS320ENT-N30
Panel BrandRisingStar
Panel ItemM320QAN02.6
Size32 inch
Panel Typea-Si TFT-LCD, LCM
Resolution: 3840*2160 UHD 163PPI
Pixel FormatRGB Vertical Stripe
Display Area708.48*398.52(H*V)mm
Outline Size 721.88*417.87*40.61(H*V*D)mm
Bezel Area//
Surface Treatment Antiglare (Haze 25%), Hard coating (3H)
Brightness3000cd/m²-3000cd/m² RisingLCD customized
Constrast Ratio.4000:1
View Angle89/89/89/89(Min)
Display ModelAHVA Normally Black, transmissive Display
Best View on Symmetry
Response Time12 (Typ.)(G+G) ms
Display Color1.07B, 100% , Srgb-
Backlight51 pins V-by-One 8 lane,
Touch Screen Without
Panel Weight 4.76 (Typ.)
Frame Rate60Hz
Signal Interface Edp (8 Lanes), 51pins connector
Input Voltage 12V(Typ.)
Operating Temperature-20 ~ 70 °C
Storage Temperature-30 ~ 80 °C
Current State: In Production

M320QAN02.6 is a 32.0-inch LCD module product using a-Si TFT-LCD Technology , It is equipped with mini LED backlight, including LED driver, backlight drive and no touch, the display resolution is 3840 (RGB) × 2160 (UHD), the aspect ratio is 16:9 (width: height), and the pixels are arranged in RGB vertical strips. Its display area size is 708.48 × 398.52 (W) × Height) mm, appearance size 721.88 × 417.87 (width) × High) × 40.61 (thick) mm, the surface treatment is haze (25%), hard coating (3H), this this product adopts the direct down light source of mini led. The service life of the light source is 50K hours.

With RisingLCD designs and customized, M320QAN02. 6 can achieve 3000nits high brightness and put a quantum dot layer between the RisingStar LCD screen and its led backlight, it changed to a QLED display, it produces brighter colors that are more heavily saturated than the traditional LED montior, the quantum dot layer can change the LED spectrum to low the blue color, and balance the R/G/B peak which can evenly stimulate people’s cone celles and effectively reduce visual fatigue. they are widely applying for the advertising industry, LCD monitor, industrial equipment, TV monitor, outdoor advertising screen, game monitor, digital signage.

32 inch QLED 4K high brightness digital signage display

QLED helps to extend the colour spectrum with solutions for implementing black such as direct full array. the viewing experience of the QLED is more realistic than the OLED display. With this 4K QLED display, the customer can experience superior pictures quality and optimized visibility for outside environment, perfect for meeting the demands of the business.

With 3000nit customized high brightness, you do not worry the brightness even the suns rays are beating down on your digital signage display, the panels are well equipped to make your content vividly stand out in any commercial location. And the The 4K Ultra HD picture quality ensures perfect colour and rich images in all possible surroundings, ranging from stores, to restaurants and office buildings.

AUO M320QAN02

OEM and ODM are welcomed!

RisingLCD is a professional highlight LCD manufacturer from China, specializes in manufacturing and distributing all types of LCD module, LCD monitors, outside and inside digital signage and goods are exported all of the world, could customize the products based on the customer needs with a competitive price, RisingLCD is your best choice!

OEM / Customized Services

01 / Chassis & Materials

Structural integrity for extreme environments.

Enclosure Grade Medical and Food grade SUS316L Stainless Steel, AL5052 Aluminum, or SECC Galvanized Steel.
Protection Rating Certified IP65 / IP69K waterproof sealing. Mechanical impact protection rated at IK10.
Surface Finish Industrial powder coating (RAL spectrum), sandblasting, and anti-acid marine painting.
Format Architecture Chassis-mount, Open-frame, Panel-mount, and VESA-integrated configurations.

03 / Interface & I/O

Industrial signal and power regulation.

Connectors Support for M12 Aviation Circular Connectors, DB9/RS232, and waterproof RJ45/USB.
Power Regulation Wide voltage DC 9V - 36V input with integrated surge and polarity protection.
Sensor Suite Integrated ambient light sensors, thermal probes, and custom GPIO control protocols.

02 / Optical & Display

Visibility optimization for extreme ambient lighting.

Luminance Output Scalable 1500 - 5000 Nits with integrated Hi-Tni (110°C) anti-blackening technology.
Optical Bonding Full Vacuum Optical Bonding (OCR) — eliminates air gaps, fogging, and maximizes contrast ratio.
Advanced Coating Integrated AR (Anti-Reflective), AG (Anti-Glare), and AF (Anti-Fingerprint) nano-films.

04 / Embedded & Data

Software architecture and data sync.

Operating Systems Full compatibility with Windows 7, 10/11 IoT; Linux support covering the last 3 generations (Ubuntu 20.04, 22.04, 24.04 LTS) and Debian; as well as comprehensive support for Android 11 through 14.
Communication High-speed 4G/5G LTE modules, Dual-band Wi-Fi 6, and Gigabit Ethernet.
