37.6 inch stretch TFT LCD digital signage for public transport station
| Brand | BOE |
| Model name | RS376ENT-N20 |
| Screen size | 37.6" |
| Screen type | Stretched LCD |
| Resolution | 1920(RGB)×540 |
| Brightness (cd/m²) | 2000 |
Risingstar 37.6 inch wide stretch TFT LCD display is designed to meet the special applications, it is with 2000 nits high brightness and ultra-wide aspect ratio that is ideal for grabbing your audience’s attention, and give perfect visual performance in a wide outdoor public application.
The stretch TFT LCD displays most of time used for digital signage and public transport suitable for applications in public transport like bus and Train or Retail. We also offer sunlight readable high bright bar types stretched display which brightness is up to 3000 nits, and size from 19.5 inch to 90 inch, it is suitable for ticket and vending machines and outdoor waterproof requirements.
The working temperature of this 37.6 inch wide stretch LCD display is -20 ~ 70°C, and the storage temperature is -30 ~ 80°C. The aspect ratio is >3:1 (width:height), and the pixels are arranged in RGB vertical stripes. Its display area size is 919.296 (width) × 258.552 (height) mm, the appearance size is 964.5 (width) *303.8 (height) *75 (thickness ) mm.
Stretch LCD Display Feature
Ultra Wide aspect ratio
Slim Bezel Bar LCD Design
2000 nits High Brightness
Wide Viewing Angle
LED Backlight and long life time
Anti-Shock
Low Power Consumption
| Factory Model No: | RS376ENT-N20 |
| Panel Brand | BOE Display |
| Panel No.: | RV376FBB-N00 |
| Screen Size | 37.6" |
| Panel Type. | IPS a-Si TFT-LCD, |
| Active Area(mm) | 919.296*258.552 (H×V) |
| Aspect Ratio | 16:4.5 |
| Native Resolution | 1920*540 (FHD) |
| Refresh Rate | 60Hz |
| Brightness | 2000nit (Typ, w/ Glass) |
| Contrast Ratio | 1000:1 (Typ) |
| Dynamic CR | 500,000:1 |
| Color gamut | NTSC 72% |
| Viewing Angle (H x V) | 178 x 178 |
| Support Color: | 16.7M /1.07B, 72% NTSC |
| Response Time | 14 (Typ.) (G to G)ms |
| Surface Treatment (Haze) | Hard coating (3H), Antiglare (Haze 1%) |
| Life time | 50,000 Hrs (Typ) |
| Operation Hours (Hours/Day) | 24/7 |
| Operating Temperature: | -20 ~ 70 °C |
| Storage Temperature: | -30 ~ 80 °C |
| Portrait / Landscape | Yes / Yes |
01 / Chassis & Materials
Structural integrity for extreme environments.
Medical and Food grade SUS316L Stainless Steel, AL5052 Aluminum, or SECC Galvanized Steel.
Certified IP65 / IP69K waterproof sealing. Mechanical impact protection rated at IK10.
Industrial powder coating (RAL spectrum), sandblasting, and anti-acid marine painting.
Chassis-mount, Open-frame, Panel-mount, and VESA-integrated configurations.
02 / Optical & Display
Visibility optimization for extreme ambient lighting.
Scalable 1500 - 5000 Nits with integrated Hi-Tni (110掳C) anti-blackening technology.
Full Vacuum Optical Bonding (OCR) - eliminates air gaps, fogging, and maximizes contrast ratio.
Integrated AR (Anti-Reflective), AG (Anti-Glare), and AF (Anti-Fingerprint) nano-films.
03 / Interface & I/O
Industrial signal and power regulation.
Support for M12 Aviation Circular Connectors, DB9/RS232, and waterproof RJ45/USB.
Wide voltage DC 9V - 36V input with integrated surge and polarity protection.
Integrated ambient light sensors, thermal probes, and custom GPIO control protocols.
04 / Embedded & Data
Software architecture and data sync.
Full compatibility with Windows 7, 10/11 IoT; Linux support covering the last 3 generations (Ubuntu 20.04, 22.04, 24.04 LTS) and Debian; as well as comprehensive support for Android 11 through 14.
High-speed 4G/5G LTE modules, Dual-band Wi-Fi 6, and Gigabit Ethernet.
