    Manufacturer: Rising Model RS185ENT-N10

    2021-10-19 09:50:09  News

    Resolution 1366 (RGB) x 768 WXGA 84 ppi pixel permutation RGB Vertical strip < br / > the LCR Vertical Stripe: left right Vertical strip < br / > a Rectangle, square < br / > RGB Delta:

    RGB Vertical Stripe:

    RGB Vertical Stripe:

    RGBW Rectangle: Red green blue white square < BR />RG/BW PenTile: (Red green)(blue and white) Vertical stripes < BR />RG/BG PenTile: (red green)(blue and green) Vertical stripes < BR />RGBY Vertical Stripe: Red, green, blue and yellow



    Display area (horizontal) 409.8 x 230.4 mm (vertical) appearance size 430.4 (horizontal) x 254.6 (vertical) x 10.4 mm (thickness)



    Open area 413.4(horizontal)×234.0(vertical) mm surface treated fog surface, Hard coating (3H)



    Display brightness 1000 CD /m² (Typ.) to ratio 1000:1 (Typ.) (transmission)



    Recommended viewing Angle - Response time 3.6/1.4 (Typ.)(Tr/Td) ms



    Viewing Angle 85/85/80/80 (Typ.)(CR10) Left/right/up/Down display mode TN, always white display, transmission < BR />IPS hard screen series: AAS, ADS, AHVA, FFS, IPS, New Mode2, PLS, SFT, Vistarich< BR />VA series: ASV, HVA, MVA, PVA, SVA, UV²A, VA



    Support 16.7m color, 72% NTSC light source type WLED [7S4P], 30K hours, no drive



    Weight 1.29Kgs (Typ.) application computer monitor



    Frame frequency 60Hz touch technology without touch



    Port type 30 Pins LVDS (1 CH, 8-bit), terminal



    Voltage supply 5.0V (Typ.)



    Operating temperature: 0 ~ 50 °C; Storage temperature: -20 °C to 60 °C



    50 °C ; 存储温度: -20 ~ 60 °C
