Manufacturer: RisingLCD model RS173ENT-N10

calendar_month Oct 15, 2021
person By RisingStar Engineering Team

Resolution 1920 (RGB) x 1080 FHD 127 ppi pixel permutation RGB Vertical strip < br / > the LCR Vertical Stripe: left right Vertical strip < br / > a Rectangle, square < br / > RGB Delta:

RGB Vertical Stripe:

RGB Vertical Stripe:

RGBW Rectangle: Red green blue white square < BR />RG/BW PenTile: (Red green)(blue and white) Vertical stripes < BR />RG/BG PenTile: (red green)(blue and green) Vertical stripes < BR />RGBY Vertical Stripe: Red, green, blue and yellow



Display area 381.888 x 214.812 mm Dimensions 403 x 240 x 13 mm



Open area 385.09(horizontal)×218.01(vertical) mm Surface treatment mirror (Haze 0%), Hard coating (3H)



Display brightness 1000 CD /m² (Typ.) to 600:1 (Typ.) (transmission)



Recommended viewing Angle - Response time 37/3 (Typ.)(Tr/Td) ms



Viewing Angle 80/80/60/80 (Typ.)(CR≥10) Left/right/up/Down display mode TN, always white display, transmission < BR />IPS hard screen series: AAS, ADS, AHVA, FFS, IPS, New Mode2, PLS, SFT, Vistarich< BR />VA series: ASV, HVA, MVA, PVA, SVA, UV²A, VA



Support 16.7m color, 72% NTSC light source type WLED, 50K hours, including LED driver



Weight 1.08Kgs (Typ.) for industrial applications



Frame frequency 60Hz

120Hz (60Hz input) : built-in MEMC circuit

120Hz+120Hz: 120Hz panel +120Hz backlight

240Hz (60Hz input) : built-in MEMC circuit touch technology without touch



Port type 30 Pins LVDS (2 CH, 8-bit), terminal



Voltage supply 3.3V (Typ.)



Operating temperature: 0 ~ 70 °C; Storage temperature: -30 to 75 °C
