215 inch sunlight readable tft LCD monitor

calendar_month Oct 11, 2021
person By RisingStar Engineering Team

Risinglcd 700 nits 1000 nits 1500 nits 2000 nits 21.5-inch TFT LCD monitor, sun-readable LCD monitor, 10 to 110 inches, up to 5000 nits, mirror monitor, outdoor waterproof digital signage, bus stop information screen, Outdoor highlight digital signage, outdoor monitor, outdoor TV, terrace TV, touch monitor, open monitor, waterproof grade: ip67, explosion-proof grade IK10,

Brand: RISINGLCD Model Name: RS215ENT-N20

Screen size: 21.5 inches Screen type: LCD module, a-Si TFT-LCD

Resolution: 1920(RGB)×1080 Pixel configuration: RGB vertical bar

Display size: 476.064×267.786 mm (H×V) Appearance size: 501.1×292.2×16.12 mm (H×V×D)

Visual size: 480.7×271.8 mm (H×V) Surface treatment: matte, Hard coating (3H)

Brightness: 2000 nits Contrast degree: 1300:1

Best angle: full viewing angle Optical mode: AHVA, normally black display, transmissive

Viewing angle: 89/89/89/89 Response speed: 25 ms

Number of colors: 16.7M, 72% NTSC backlight type: 4 strings×2CN WLED, 50K hours, no driver

Screen weight: 2.10Kgs Suitable for: digital signage outdoor highlight

Refresh rate: 60Hz

Signal system: LVDS (2 ch, 8-bit), terminal, 30 pins

Supply voltage: 5.0V (Typ.)

Maximum rating: Storage temperature: -20 ~ 85 °C Working temperature: -20 ~ 85 °C
